MULTICOMP PRO ME04050802 Pluggable Terminal Block
The ME040-50802 is a 2-pole pluggable terminal block header rated for 16A with a through-hole vertical mounting design. It features tin-plated brass solder pins and a green polyamide 66 insulating body. The terminal block has a UL94V-0 flammability rating, an insulation resistance of over 2000 MΩ at 200VDC, and can operate within a temperature range of -40°C to 105°C. Suitable for industrial applications, this product is part of the Multicomp Pro line, which is rated 4.6 out of 5 stars by customers and includes a 12-month limited warranty.
MULTICOMP PRO ME04050802 Pluggable Terminal Block Specifications:
- Current Rating: 16 Amp AC300V
- Insulation Withstands Voltage: AC2000V min
- Insulation Resistance: >2000 MΩ DC200V
- Operation Temperature: -40°C to +105°C
- Material: Insulating body Polyamide 66 (UL94V-0)
- Solder Pin Material: Brass, Tin plated
- Pitch: 5.08mm (0.2")
- Pole: 2
- Dimensions: Length varies with model, typical pin length approximately 11.76 mm (0.463 inches)
Buy the Multicomp Reliable 50802 U+2013 Reliable Pluggable Terminal Block for Industrial Applications
Secure your industrial connections with the Pluggable Terminal Block rated for 16A, featuring UL94V-0 flammability and a robust insulation resistance. Its vertical, through-hole design ensures easy installation, while the tin-plated brass pins guarantee lasting conductivity. Operating from -40°C to 105°C, this terminal block is suitable for demanding industrial environments. With a compact 5.08mm pitch and 2 poles, it provides reliable, safe electrical connections. Order online to enhance your wiring system with this dependable, high-quality component.
Buy Multicomp ME040-50802 now and experience unmatched reliability and performance in industrial wiring solutions.
Frequently Asked Questions
Where can I buy MULTICOMP PRO ME04050802?
You can click on the BUY or RFQ button to purchase ME04050802 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part ME04050802?
You can download the ME04050802 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of ME04050802?
MULTICOMP PRO
