MULTICOMP PRO MINI113 Coaxial Cable
The Mini 1.13 Coaxial Cable is a high-quality FEP-insulated cable designed for reliable signal transmission up to 6GHz. It features a silver-plated copper inner conductor and shield, with a grey FEP jacket that provides excellent flexibility and durability. Capacitance is 98pF/m, and it has a maximum operating temperature of +155°C. The cable's low attenuation at 20°C ensures minimal signal loss. Suitable for high-frequency applications, this coaxial cable offers 2500VRms spark test resilience and a minimum bend radius of 4.5mm for flexible installation in dense environments.
MULTICOMP PRO MINI113 Coaxial Cable Specifications:
- Inner Conductor Material: Silver Plated Copper 7/0.08
- Dielectric Material: FEP 0.68 mm
- Shield Material: Silver Plated Copper 0.9 mm
- Jacket Material: FEP (Grey) 1.13 mm
- Impedance: 50Ω ± 3Ω
- Capacitance: 98pF/m
- Velocity of Propagation: 169%
- Max. Operating Frequency: 6 GHz
- Dielectric Strength: 500V AC / Minute
- Rating Current: 21.54A
- Minimum Bend Radius: 4.5mm
- Spark Test Voltage: 2500VRms
- Operating Temperature Range: -55°C to +155°C
- Attenuation (@20°C): 1 GHz - 24 dB/m, 2 GHz - 3.3 dB/m, 3 GHz - 3.4 dB/m, 4 GHz - 4.6 dB/m, 6 GHz - 5.6 dB/m
- Length Options: 25 Meter or 100 Meter
Buy the Buy Multicomp Coaxial Cable Part Number MINI113 Online
Purchase the high-quality Multicomp coaxial cable MINI-1.13 online for reliable performance up to 6GHz. Featuring silver-plated copper conductors and FEP insulation, this cable is ideal for RF, communications, and signal transmission. Its durable grey FEP jacket provides excellent flexibility, allowing easy installation in tight spaces. With a low attenuation rate, it ensures minimal signal loss, making it perfect for critical applications. Available in 25-meter and 100-meter lengths, order now to ensure your projects benefit from this dependable, high-frequency coaxial cable.
Get Multicomp coaxial cable MINI-1.13 today—built for high-frequency RF signals and exceptional flexibility in demanding environments.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MINI113?
You can click on the BUY or RFQ button to purchase MINI113 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MINI113?
You can download the MINI113 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MINI113?
MULTICOMP PRO
