MULTICOMP PRO MP001913 Power Fuse
This ceramic cartridge power fuse measures 14.6mm x 38.5mm and is designed for over-current protection in high voltage applications. It features a 63A current rating, 600V AC voltage rating, and a ceramic body with tin-plated copper termination material. Suitable for through-hole mounting, it offers a melting current of 9892.95A at 250V, ensuring reliable circuit protection. The fuse withstands operating temperatures from -55°C to 125°C, making it ideal for high-voltage electrical systems requiring quick response and durability in demanding environments.
MULTICOMP PRO MP001913 Power Fuse Specifications:
- Current Rating: 63A
- Voltage Rating: 600V AC
- Interrupting Current Rating: 1,500A at 600V, 2,000A at 250V, 500A DC at 125V
- Fuse Body Material: Ceramic
- Termination Material: Tin Plated Copper
- Operating Temperature: -55°C to 125°C
- Dimensions: 14.6mm x 38.5mm
- Type: Through hole
- Nominal Cold Resistance: 0.00130 Ohms
- Min. Rating: 63A for 4 hours
- Melting I't: 9892.95A at 250V
- Part Number: MP001913
Buy the Multicomp Series Power Fuse: Ceramic Cartridge 14.6mm x 38.5mm MP001913
Purchase the Multicomp ceramic cartridge power fuse MP001913 today for high-current circuit protection up to 63A and 600V AC. Its ceramic body with tin-plated copper terminals provides durability and reliable performance in demanding high-voltage environments. Suitable for through-hole mounting, this fuse ensures quick response during overload situations and is engineered to withstand operating temperatures from -55°C to 125°C. Ideal for industrial, commercial, and high-voltage electrical applications where safety and durability are critical.
Buy Multicomp MP001913 power fuse now and experience unmatched reliability and high voltage protection in demanding electrical systems.
