MULTICOMP PRO MP002735 M12 Push-Pull Connector
The MP M12 push-pull connectors are made from chrome-plated brass, combining durability for tough environments with an attractive appearance. These connectors are available in panel mount, cable mount, and in-line cable mount configurations, offering options for cable-to-cable or cable-to-panel connections. They feature a push-pull coupling mechanism for easy engagement and disengagement, and are rated IP67 for weather resistance, making them suitable for both indoor and outdoor applications. The connectors fit a 12mm panel cut-out, utilize solder termination, and come in 2, 4, 5, and 7 pole versions. They are ideal for use in automation, medical, security, test and measurement, and industrial automation industries.
MULTICOMP PRO MP002735 M12 Push-Pull Connector Specifications:
- Material: Chrome-plated brass for durability
- Coupling: Push-pull mechanism for easy connection
- Ingress Protection: IP67 weather resistant
- Temperature Range: -40°C to +85°C
- Number of Poles: 2, 4, 5, 7
- Contact Material: Brass with gold plating
- Termination: Solder
- Shell Material: Brass with chrome plating
- Insert Material: PPS, Max. Temperature 260°C
- Contact Diameter: 1.6mm (for 2 poles), 1mm (for 4, 5, 7 poles)
- Rated Current: 13A (2 poles), 5A (others)
- Rated Voltage: 250V (2 poles), 200V, 180V, 125V (others)
- Test Voltage: 1500V (2,4 poles), 1000V (others)
- Mating Cycle: 500
- Panel Cutout: 3.5 mm max
- Outer Diameter Range: 4mm to 6.5mm
- Dimensions: 19/03/20 V1.0 millimetres
- Applicable Industry: Automation, Medical, Security, Test & Measurement, Industrial
Buy the Buy Multicomp M12 Push-Pull Connector Part Number MP002735 Online
Purchase the Multicomp M12 Push-Pull Connector MP002735 online today and enjoy reliable, weather-resistant connectivity solutions for automation, industrial, and security applications. These connectors feature a robust push-pull coupling design, IP67 protection rating, and range in configurations to suit your needs. Easy to install with solder termination, they support a wide temperature range from -40°C to +85°C and are rated for up to 13A current. Perfect for outdoor and indoor use, ensuring long-lasting durability and dependable performance.
Get Multicomp M12 Push-Pull Connector MP002735 today—designed for secure connections in demanding industrial environments.
