MULTICOMP PRO MP002745 Industrial M12 Connector
The MP M12 push-pull connectors are chrome-plated brass connectors designed for durability and aesthetic appeal. They are suitable for harsh environments and feature a push-pull coupling mechanism for quick and easy connection and disconnection. Available in panel mount, cable mount, and in-line configurations, these connectors support cable-to-cable or cable-to-panel connections. Rated IP67 for weather resistance, they are ideal for indoor and outdoor use. Supporting 2, 4, 5, or 7 poles, they are used in automation, process control, medical, security, and industrial automation sectors.
MULTICOMP PRO MP002745 Industrial M12 Connector Specifications:
- Coupling: Push-pull
- Shell Material: Brass with chrome plating
- Insert Material: PPS, Max. Temperature 260°C
- Contact Material: Brass with gold plating
- Termination: Solder
- IP Rating: IP67
- Mating Cycle: 500
- Temperature Range: -40°C to +85°C
- Insulation Resistance: 2000 MΩ
- Number of Contacts: 2, 4, 5, 7
- Rated Current: 13A (2 contacts), 5A (4, 5, 7 contacts)
- Contact Diameter: 1.6 mm (2 contacts), 1 mm (others)
- Rated Voltage: 250V (2 contacts), 200V, 180V, 125V (others)
- Test Voltage: 1500V (2 contacts), 1000V (others)
- Contact Resistance: 2.5 mΩ (2 contacts), 5 mΩ (others)
- Outer Diameter Range: 4mm to 6.5mm
- Panel Cutout: 3.5 mm max
Buy the Multicomp Series M12 Push-Pull Connectors: MP002745
Order the Multicomp M12 Push-Pull Connectors MP002745 online today. These high-quality, weather-resistant connectors are perfect for automation, industrial control, and outdoor applications. Designed with durable chrome-plated brass shells, they support quick and secure connections through push-pull coupling. Available in panel, cable, and inline configurations with various contact poles, rated IP67 for protection. Enjoy fast delivery and reliable performance for your industrial or outdoor projects by purchasing online now.
Buy Multicomp M12 Push-Pull Connectors MP002745 now and experience unmatched durability, quick connection, and high weather resistance ideal for industrial automation.
