MULTICOMP PRO MP002801 Power Inductor
This unshielded SMD power inductor is designed for high power applications in electronic devices. Suitable for DC-DC converters in portable electronics, it features high saturation current and operates efficiently within -40°C to 125°C. The 1608 case version uses a ceramic base with gold plating, offering reliable performance for notebooks, PDAs, flash memory programmers, and various electronic appliances. Its compact size supports surface-mount technology, ensuring easy integration with minimal PCB space consumption and high thermal stability.
MULTICOMP PRO MP002801 Power Inductor Specifications:
- Case Code: 1608, 3316, 5022
- Dimensions (mm): 1608 - 6.60 x 4.45 x 2.92, 3316 - 12.95 x 9.4 x 5.21, 5022 - 18.54 x 15.24 x 7.11
- Operating Temperature Range: -40°C to 125°C
- Saturation Rated Current: Current at which inductance drops 10%
- Material: Ceramic base with gold plating for case 1608, LCP plastic base for others
- Application: DC-DC converters, portable telephones, personal computers, electronic appliances
- Inductance Values: 2.2 μH, 47 μH, 6.8 μH, 10 μH, 22 μH, 150 μH, 470 μH, 1000 μH, 33 μH, 100 μH, 150 μH, 330 μH, 680 μH, 1000 μH, 15 μH, 100 μH, 470 μH, 1000 μH
- Resistance: Ranging from 0.007 Ω to 6 Ω depending on model
- Tape Reel Packaging: 2000 units for 1608, 1000 for 3316, 250 for 5022
- Temperature & Humidity Tests: Storage from 15°C to 28°C with <80% humidity, tested under high/low temperature and humidity conditions
- Mechanical & Soldering: Terminal coverage ≥90%, resistance to soldering heat, vibration, shock; reflow peak temperature 265°C
- Electrical Ratings: Inductance from 2.2 μH to 1000 μH, max DCR between 0.07 Ω and 13.8 Ω, maximum current from 0.7 A to 8 A
Buy the Multicomp MP002801 – Reliable Power Inductor for Industrial Applications
Purchase the Multicomp power inductor MP002801 now and ensure reliable performance in your DC-DC conversion and portable electronics. Designed for high saturation current and operating temperatures up to 125°C, this surface-mount device offers excellent stability, minimal PCB space, and robust build quality. Ideal for applications such as notebooks, PDAs, flash memory programming, and various electronic appliances, order online today for fast delivery and technical support, enhancing your electronic project with proven performance and durability.
Get Multicomp power inductor MP002801 today—built for high power and long-lasting durability in electronic devices.
