MULTICOMP PRO MP004300 Ceramic Cartridge Fuse
This fast-acting ceramic cartridge fuse with axial leads measures 6.3mm by 32mm, suitable for high-reliability circuit protection in various electronic applications. Made with a ceramic body and nickel-plated brass caps, it offers an interrupting rating up to 10,000A at 125V AC and operates within a temperature range of 1-55°C to 125°C. The fuse's thermal characteristics ensure quick response to overload conditions, preventing damage to sensitive components, making it ideal for AC/DC systems requiring precise circuit protection and durability.
MULTICOMP PRO MP004300 Ceramic Cartridge Fuse Specifications:
- Body Material: Ceramic
- Cap Material: Nickel-plated Brass
- Dimensions: 6.3mm x 32mm
- Interrupting Rating: Up to 10,000A at 125V AC, 400A at 125V DC
- Voltage Rating: 125V AC, 250V AC (up to 30A ratings)
- Current Ratings: 500mA to 30A
- Operating Temperature: 1-55°C to 125°C
- Rated Breaking Capacity: 10,000A at 125V AC
- Lead Diameter: 0.8mm
- Lead Length: 38mm ±2mm
- Certifications: UL Listed, CSA Certified, Recognized Component for US and Canada
Buy the Buy Multicomp Ceramic Cartridge Fuse Part Number MP004300 Online
Get the reliable and fast-acting ceramic cartridge fuse MP004300 online today. Perfect for protecting sensitive electronic circuits, this fuse features a ceramic body and nickel-plated brass caps. With a 6.3mm x 32mm size, it offers high interrupting ratings up to 10,000A at 125V AC and operates within a temperature range of 1-55°C to 125°C. Easy to install, its robust construction ensures durability and consistent performance in both AC and DC systems, enhancing safety and equipment longevity.
Order your Multicomp Series MP004300 ceramic cartridge fuse today and ensure reliable circuit protection with quick acting response and high current capacity.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004300?
You can click on the BUY or RFQ button to purchase MP004300 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004300?
You can download the MP004300 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004300?
MULTICOMP PRO
