MULTICOMP PRO MP004337 Ceramic Cartridge Fuse
The Time-Lag Ceramic Cartridge Fuse is an axial leaded fuse designed for circuit protection in various electrical applications. It features a ceramic body with nickel-plated brass caps, suitable for rated currents from 800mA to 30A and rated voltages up to 250V AC or DC. Its compact 6.3mm diameter and 32mm length make it ideal for space-constrained environments. The fuse provides reliable, fast or time-lag protection, with high interrupting ratings, UL, CSA, and PSE approvals. Operating temperature ranges from -55°C to 125°C, ensuring durability across diverse conditions.
MULTICOMP PRO MP004337 Ceramic Cartridge Fuse Specifications:
- Diameter: 6.3 mm
- Length: 32 mm
- Body Material: Ceramic
- Cap Material: Nickel Plated Brass
- Lead Wire Diameter: 0.8 mm (12A and less), 1.0 mm (13A to 19A), 1.2 mm (above 20A)
- Operating Temperature Range: -55°C to 125°C
- Rated Voltage: Up to 250V AC/DC
- Rated Current: 800mA to 30A
- Interrupting Rating: Up to 10,000A at 125V AC, 750A at 250V AC
- Compliance: UL Listed, CSA Certified, PSE
- Dimensions: 6.3mm x 32mm, with total length including caps approximately 33mm
Buy the Multicomp Series Time-Lag Ceramic Fuse: MP004337
Upgrade your electrical setups with the reliable ceramic cartridge fuse designed for circuit protection in a compact 6.3mm x 32mm form factor. Suitable for AC and DC applications, it features high interrupting ratings and broad compatibility with UL, CSA, and PSE approvals. With operating temperatures from -55°C to 125°C, this fuse offers durability and safety. Ideal for various electrical devices requiring fast or time-lag protection, ensuring optimal performance and safety in industrial and commercial applications. Buy online now for fast delivery and quality assurance.
Order your Multicomp Series Time-Lag Ceramic Fuse MP004337 today and ensure reliable circuit protection in your electrical projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004337?
You can click on the BUY or RFQ button to purchase MP004337 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004337?
You can download the MP004337 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004337?
MULTICOMP PRO
