MULTICOMP PRO MPDRA24048A Industrial DC Power Supply
This 240W AC to DC power supply is designed for industrial use, featuring DIN rail mounting, auto-select input voltage of 115/230V AC, PFC function, and parallel switch capability. It provides reliable output voltages of 24V and 48V with high efficiency up to 90%. The unit includes protective features like overvoltage, overcurrent, and short circuit protections, meeting standards such as UL 508 and EN 60950-1. Compact and rugged, it supports general industrial applications requiring stable power conversion, long MTBF, and easy installation with screw terminals and convection cooling.
MULTICOMP PRO MPDRA24048A Industrial DC Power Supply Specifications:
- Input Voltage: 115/230 VAC (auto select), 90-132 VAC at 115V, 180-264 VAC at 230V
- Output Voltage: 24V DC (5A, 85% efficiency), 48V DC (5A, 88% efficiency)
- Power Dissipation: 32-35 W at 230VAC, Power factor: 0.75 (230V AC input)
- Isolation Voltage: Input-Output 3000/4242 VAC, Input-FG 1500/2121 VAC
- Dimensions: 124.5 mm x 83.5 mm x 123.6 mm, Metal case, Weight: 1380 g
- Operating Temperature: -40°C to +71°C, Storage: -40°C to +85°C
- MTBF: Over 60,000 hours, Cooling: Free air convection, Pollution degree 2
- Protection: Overvoltage (30-66 VDC), Short circuit, Overload (120-145%), IP20 rated
- Standards: UL 508, UL 60950-1, EN 61000-4-x, CE, Vibration and shock resistant
Buy the Multicomp 240W Power Supply – Reliable Industrial AC to DC Conversion for Automation
Enhance your industrial automation setup with this high-quality 240W AC to DC power supply from multicomp. Designed for DIN rail mounting, it features auto-select input voltage of 115 or 230V AC, high efficiency up to 90%, and protection against overvoltage, overcurrent, and short circuits. Compact and robust, it supports continuous operation in demanding environments with excellent thermal performance and long MTBF over 60,000 hours. Ideal for controlling industrial equipment, machinery, and automation systems, it ensures stable power delivery with easy installation and compliance to international standards.
Buy multicomp 240W power supply now and experience unmatched reliability, high efficiency, and easy DIN rail installation for industrial automation.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MPDRA24048A?
You can click on the BUY or RFQ button to purchase MPDRA24048A from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MPDRA24048A?
You can download the MPDRA24048A datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MPDRA24048A?
MULTICOMP PRO
