MULTICOMP PRO MPEC8025M12EA Cooling Fan
This is a 12V DC fluid bearing cooling fan measuring 80 x 80 x 25 mm. It features a three-pin connector, a fan speed of 2500 RPM, and comes with mounting screws. Designed for effective cooling applications, it offers quiet operation and reliable performance. The fan operates within a voltage range of 7V to 13.8V DC, with a maximum airflow of 32W at 500 RPM, and noise levels below 28 dB(A). Made with high-quality thermoplastic materials, it ensures durability and long life for industrial cooling needs.
MULTICOMP PRO MPEC8025M12EA Cooling Fan Specifications:
- Rated Voltage: 12V DC
- Starting Voltage: 7V DC
- Operating Voltage Range: 7V DC to 13.8V DC
- Rated Current: 1A
- Rated Power Consumption: 32W
- Rated Speed: 2500 RPM
- Maximum Airflow: 5.02 CFM (ft³/min)
- Maximum Static Pressure: 0.08 In-H2O
- Noise Level: <28 dB(A)
- Life Expectancy: 40,000 hours at 25°C
- Polarity Protection: Yes (Endurance when Vcc & GND are exchanged)
- Auto Restart: No
- Insulation Resistance: 10MQ/b/w unshielded wire and frame at 500V DC/min
- Dielectric Strength: 5Ma Max. between lead wire and frame at 500V AC/min
- Materials of Frame: Thermoplastic PBT of UL 94V-0 (Black)
- Materials of Fan Blade and Bobbin: Thermoplastic PBT of UL 94V-0 (Black)
- Bearing: EL bearing
- Lead Wires: Red (+), Black (-), Yellow (FG) (UL1007, 26 AWG)
- Connector: 2510 3P
- Operation Temperature: -10°C to +70°C / 66% RH
- Storage Temperature: -40°C to +70°C / 66% RH
Buy the Multicomp Reliable 8025M12EA for Industrial Cooling Fans
Enhance your cooling solution with the reliable 80mmx80mmx25mm 12V DC axial fan. Featuring high efficiency, low noise, and long lifespan, it is perfect for industrial and electronic cooling needs. Easy to install with a three-pin connector, it guarantees consistent airflow at 2500 RPM while operating quietly below 28 dB(A). Made from durable thermoplastic materials, this fan provides optimal performance and durability in challenging environments. Purchase online today to ensure effective thermal management for your equipment.
Buy Multicomp 8025M12EA now and experience unmatched reliability and performance in industrial cooling applications.
