MULTICOMP PRO PP002164 Twin and Earth PVC Cable
The twin and earth PVC cable is suitable for domestic wiring in dry or damp premises, clipped to surfaces, in trays, or in conduit where mechanical protection is necessary. It features copper conductors complying with BS EN 60228, with solid or stranded conductors depending on size. The cable's PVC Type Tl1 insulation and Type 6 sheath meet BS EN 50363 and BS 7655 standards, respectively. Fully RoHS compliant, it handles voltages up to 300/500V, operates from -5°C to +70°C, and has a minimum bending radius of 6 times the overall diameter. The cable color is grey, with core identification by brown and blue, and is available on reels or per meter.
MULTICOMP PRO PP002164 Twin and Earth PVC Cable Specifications:
- Voltage Rating (Uo/U): 300/500V
- Temperature Rating: -5°C to +70°C
- Short Circuit: +160°C
- Minimum Bending Radius: 6 x overall diameter
- Core Identification: Brown, Blue
- Sheath Colour: Grey
- Conductors: Copper according to BS EN 60228, solid or stranded depending on size
- Insulation: PVC Type Tl1 BS EN 50363
- Sheath: PVC Type 6 BS 7655
- Cable Standards: BS 6004 Table 4
- Available on reels of 100m or per metre
- Physical Dimensions vary by cross-sectional area, e.g., 1mm2, 1.5mm2, 2.5mm2, 4mm2, etc.
- Conductor resistance for 20°C ranges from 18.1 Ω/km for 1mm2 to 7.41 Ω/km for 25mm2
- Current capacity varies from approximately 11.5A for 1mm2 to 57A for 16mm2 in clip or conduit installations
Buy the Multicomp Series Twin and Earth PVC Cable: PP002164
Purchase the Twin and Earth PVC cable today for your electrical wiring needs. Designed for reliable performance in fixed domestic installations, this cable features copper conductors, PVC insulation, and a durable PVC sheath. Suitable for dry or damp condition environments, the cable conforms to BS standards, offers flexible options on reels or per meter, and ensures safety and longevity. Ideal for surface mounting, conduit, or trunking, it provides excellent electrical performance and mechanical protection. Order now for fast delivery and competitive prices online.
Get Multicomp Series PP002164 twin and earth PVC cable today—built for reliable domestic wiring in dry and damp environments.
