MULTICOMP PRO PP002735 Heat Shrink Tubing
This high-quality, flexible heat shrink tubing features a 2:1 shrink ratio, suitable for protecting temperature-sensitive components. Made from radiation cross-linked polyolefin, it is halogen-free, RoHS compliant, and shrinks at low temperature. Operating between -55°C and +125°C, it provides excellent mechanical and electrical performance, including high dielectric strength and volume resistivity. Available in various diameters and colors, the tubing conforms to industry standards like Sony-SS-00259, making it ideal for wire and cable insulation, electronic component protection, and quick shrinkage applications with minimal thermal stress on components.
MULTICOMP PRO PP002735 Heat Shrink Tubing Specifications:
- Shrink Ratio: 2:1
- Operating Temperature: -55°C to +125°C
- Min. Shrink Temperature: 70°C
- Full Recovery Temperature: 120°C
- Material: Radiation cross-linked polyolefin
- Halogen Free: Yes
- Flammability: FMVSS302 Pass
- Dielectric Strength: 215 kV/mm
- Volume Resistivity: 21x10^4 Ohm·cm
- Tensile Strength: 210.4 MPa
- Ultimate Elongation: 2200%
- Longitudinal Shrinkage: 45%
- Property Test Methods: ASTM D2671, UL 224, ASTM D150
- Color Options: Black, Brown, Blue, White, Red, Yellow, Green, Grey, Grey/Yellow, Clear
- Size Range: 1.6mm to 50.8mm internal diameter, various wall thicknesses, lengths typically 1.2m or 5m
Buy the Pro-Power Series Heat Shrink Tubing: PP002735
Get your Pro-Power Series PP002735 heat shrink tubing today for top-quality, flexible insulation and protection for electronic components. Engineered with radiation cross-linked polyolefin, it shrinks efficiently at low temperatures, providing excellent electrical and mechanical performance, including high dielectric strength and resistance to flames. Offering a wide range of diameters and colors, it’s ideal for insulation, cable repair, and electronic device protection. Buy online now and ensure your projects meet the highest safety and durability standards easily and quickly.
Order your Pro-Power Series PP002735 heat shrink tubing today and secure reliable electrical insulation and protective wiring solutions.
Frequently Asked Questions
Where can I buy MULTICOMP PRO PP002735?
You can click on the BUY or RFQ button to purchase PP002735 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part PP002735?
You can download the PP002735 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of PP002735?
MULTICOMP PRO
