MULTICOMP-PRO R13112A502WW0A Rocker Switch
The Multicomp Pro R13 series rocker switches are mechanically operated, available in illuminated and non-illuminated types, with SPST and DPST configurations. They feature panel mounting, come in multiple actuator colors such as white, black, red, and green, and are suitable for industrial, automation, and power management systems. These switches have a rated current of up to 20A at 12V, with high durability exceeding 100,000 operating cycles, and are designed to perform reliably under various environmental conditions, including humidity, shock, and vibration.
MULTICOMP-PRO R13112A502WW0A Rocker Switch Specifications:
- Contact Configuration: SPST, DPST
- Actuating Force: Suitable for panel mounting
- Rated Current: 20A at 12V DC
- Contact Resistance: <100mΩ (5V, 1A DC)
- Dielectric Strength: >1,000V (new state)
- Insulation Resistance: >100MQ (500V DC)
- Temperature Range: -20°C to +65°C
- Mechanical Life: >100,000 operations
- Terminal Strength: >2.5 kg - solder terminal, >6.8 kg - plug-in / screw terminal
- Environmental Resistance: Humidity up to 85%, salt spray, shock 100g/10ms, vibration 10-55Hz/1.5mm
- Dimensions: Millimetres, suitable for panel installation
Buy the Multicomp Series R13 Rocker Switches: R13112A502WW0A
Purchase the versatile and durable Multicomp series R13 rocker switches online today for robust performance in industrial environments. These switches feature SPST and DPST configurations, with illuminated and non-illuminated options suitable for automation, power management, and control systems. Rated for up to 20A at 12V DC, they withstand over 100,000 operations, ensuring long-term reliability. Easy to install with panel mounting, these switches are built to operate reliably across temperature, humidity, shock, and vibration conditions, making them ideal for demanding industrial applications.
Buy Multicomp series R13 rocker switches now and experience unmatched reliability and performance in control applications.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO R13112A502WW0A?
You can click on the BUY or RFQ button to purchase R13112A502WW0A from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part R13112A502WW0A?
You can download the R13112A502WW0A datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of R13112A502WW0A?
MULTICOMP-PRO
