MULTICOMP PRO RBM210RAVB Rotary Switch
This high-performance rotary switch is ideal for signal switching in electronic devices, featuring a durable design rated for 10,000 cycles. It supports a maximum operating force of 400gf.cm and has excellent electrical and mechanical resilience, including an insulation resistance of at least 100MQ and dielectric strength of 250V AC for 1 minute. Designed for temperature ranges from -60°C to +125°C, it offers reliable contact resistance of 100mΩ or less. Its robust construction ensures long-term operation in demanding environments, with specifications tailored for precise and durable signal control applications.
MULTICOMP PRO RBM210RAVB Rotary Switch Specifications:
- Rating: Non Switching 24V DC 400mA, Switching 24V DC 150mA
- Life: 10,000 Steps
- Operating Force: 400gf.cm Max.
- Initial Contact Resistance: 100mΩ Max.
- Dielectric Strength: AC 250V 1 minute
- Insulation Resistance: 100MQ Min. (DC 250V Megger)
- Operating Temperature: -60°C to +125°C
- Storage Temperature: -60°C to +125°C
- Contact Resistance: 100mΩ Max.
- Dielectric Voltage: 250V AC for 1 minute
- Number of Cycles: 10,000
- Material: Thermoplastic (Nylon), Gold-Plated Contact
- Soldering Temperature: 260°C +5°C for 5 seconds
- Vibration Resistance: 10-55Hz, 1 min/cycle for 2 hours per direction
- Shock Resistance: 50G, 11±1ms, 6 directions, 3 cycles each
- Temperature Range for operation and storage: -60°C to +125°C
Buy the Multicomp Series Rotary Switch: RBM210RAVB
Enhance your electronic projects with the reliable and durable Rotary Switch designed for signal switching in demanding environments. Rated for 10,000 cycles, it operates across a temperature range of -60°C to +125°C, ensuring stability in both industrial and consumer electronics. Its high insulation resistance and precise contact resistance deliver consistent performance, making it perfect for a variety of signal control applications. Buy online now for dependable operation and seamless integration into your electronic systems.
Get Multicomp Pro RBM210RAVB today—built for precision and long-lasting durability in signal switching applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO RBM210RAVB?
You can click on the BUY or RFQ button to purchase RBM210RAVB from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part RBM210RAVB?
You can download the RBM210RAVB datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of RBM210RAVB?
MULTICOMP PRO
