MULTICOMP-PRO RBM216RBVB SMT Switch
This high-quality flat-head and cross-head SMT actuator from Multicomp Pro is designed for precision switching in electronic devices. It features a durable thermoplastic body, gold-plated contacts, and stainless steel springs, ensuring reliable performance through 10,000 switching steps. Operating within -60°C to +125°C, it offers non-switching ratings of 24V DC 400mA and switching ratings of 24V DC 150mA. Its robust construction and adherence to industry standards make it ideal for signal switching applications in various electronic assemblies.
MULTICOMP-PRO RBM216RBVB SMT Switch Specifications:
- Rating: Non Switching Rating 24V DC 400mA, Switching Rating 24V DC 150mA
- Life: 10,000 Steps
- Operating Force: 400gf.cm Max.
- Initial Contact Resistance: 100m Max.
- Dielectric Strength: AC 250V 1 minute
- Insulation Resistance: 100MQ Min. (DC 250V Megger)
- Operating Temperature: -60°C to +125°C
- Storage Temperature: -60°C to +125°C
- Soldering Temperature: Max 260°C for 4 sec
- Vibration Resistance: MIL-STD-202F Method 201A, 10-55-10 Hz 1 min/cycle
- Shock Resistance: 50G, 11±1ms, 6 sides, 3 cycles
- Material: Thermoplastic nylon, FR-4 PCB contacts, stainless steel spring, brass terminal with gold plating
- Dimensions: See detailed diagram, typical dimensions provided in millimeters
Buy the Multicomp Series SMT Switch: RBM216RBVB
Purchase the advanced SMT switch from Multicomp Pro online today for your electronic projects. Designed for high reliability, it features a durable thermoplastic body, gold-plated contacts, and a rated life of 10,000 steps. Ideal for signal switching in various devices, it operates from -60°C to +125°C, ensuring performance across a wide temperature range. Easy to integrate with typical soldering requirements at max 260°C, it offers excellent insulation resistance and dielectric strength, providing dependable operation in demanding environments. Order now for quick delivery and reliable performance.
Get Multicomp Pro RBM216RBVB today—built for precision switching and long-lasting durability in electronic applications.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO RBM216RBVB?
You can click on the BUY or RFQ button to purchase RBM216RBVB from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part RBM216RBVB?
You can download the RBM216RBVB datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of RBM216RBVB?
MULTICOMP-PRO
