MULTICOMP PRO RS3B Surface Mount Rectifier
The RS3B surface mount fast recovery glass passivated rectifier offers high efficiency with fast switching capabilities, low reverse leakage current, and low forward voltage drop. With a molded plastic case and UL 94V-0 recognition, it supports a wide temperature range from -55°C to +150°C, making it suitable for various industrial power applications. It features ratings up to 1000V reverse voltage, 3A forward current, and includes characteristics like a peak reverse recovery time of 150-500 ns, and low junction capacitance. Designed for reliable, high performance rectification in compact form factors.
MULTICOMP PRO RS3B Surface Mount Rectifier Specifications:
- Maximum Recurrent Peak Reverse Voltage: 100V, 400V, 1000V (depending on model)
- Maximum RMS Voltage: 70V, 280V, 700V (depending on model)
- Maximum DC Blocking Voltage: 100V, 400V, 1000V (depending on model)
- Forward Current: 3A at 50°C ambient
- Peak Forward Surge Current: 8.3 ms single half sine wave at 100A
- Maximum Reverse Recovery Time: 150-500 ns (depending on model)
- Junction Capacitance: 65 pF, 40 pF (depending on model)
- Operating Temperature Range: -55°C to +150°C
- Storage Temperature Range: -55°C to +150°C
- Dimensions (in inches): 0.245 x 0.103 x 0.079; (in millimetres): 6.22 x 2.62 x 2.00
- Case material: Molded plastic, UL 94V-0 rated
- Polarity: Colour band indicates cathode
- Mounting: Surface mount, any position compatibility
Buy the Multicomp RS3B – Reliable Rectifier for Industrial Applications
Purchase the Multicomp RS3B surface mount rectifier online for reliable high-speed switching and low leakage current, essential for efficient power management. Its compact molded plastic case and wide temperature range make it ideal for industrial electronics, power supplies, and automation systems. With ratings up to 1000 volts and 3 amps, it ensures high performance and durability in rugged conditions. Shop online today and experience fast delivery for this essential component designed for precision and long-lasting service in power rectification tasks.
Get Multicomp RS3B today—built for high-efficiency power rectification in demanding industrial environments.
Frequently Asked Questions
Where can I buy MULTICOMP PRO RS3B?
You can click on the BUY or RFQ button to purchase RS3B from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part RS3B?
You can download the RS3B datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of RS3B?
MULTICOMP PRO
