MULTICOMP PRO SBR2512W Bridge Rectifier
The three-phase bridge rectifier is designed to convert AC to DC power efficiently, supporting high surge currents and high reliability with low forward voltage drop. Suitable for printed circuit boards, it features epoxy case encapsulation with heat sink mounting, plated solderable leads, and rugged construction. Rated for voltages up to 1200V, it handles currents of 25A. The device operates reliably in temperatures from -55°C to +150°C, making it ideal for industrial power conversion, automation systems, and electrical infrastructure requiring durable, high-current rectification components.
MULTICOMP PRO SBR2512W Bridge Rectifier Specifications:
- Maximum RMS Reverse Voltage: 560V at 25°C
- Peak Repetitive Voltage: 800V to 1200V depending on model
- Average Forward Rectified Current: 25A
- Peak Surge Current: 430A
- Maximum Forward Voltage Drop: 14V at 12.5A
- Reverse Peak Current: 5pA (VRRM), 3mA (VR at 125°C)
- Isolation Voltage: 2500V from case to lead
- Operating Temperature Range: -55°C to +150°C
- Storage Temperature Range: -55°C to +150°C
- Thermal Operating Temperature: Up to 150°C
- Mounting: Bolt down on heatsink with silicone thermal compound, torque 2N.m
- Material: Epoxy case with heat sink, plated leads solderable per MIL-STD-202, Method 208
Buy the Multicomp 2512W – Reliable Bridge Rectifier for Industrial Applications
Purchase the Multicomp 2512W bridge rectifier online today and ensure robust, high-efficiency power conversion for your industrial or automation projects. With its high surge current capability, low forward voltage drop, and reliable operation across a wide temperature range, this rectifier is engineered for demanding electrical systems. Its epoxy case with heat sink mounting provides excellent thermal management, making it ideal for installation on printed circuit boards. Secure your supply chain by ordering this durable, high-performance rectifier from authorized distributors now.
Buy Multicomp 2512W now and experience unmatched reliability and high current capacity perfect for your industrial power conversion needs.
Frequently Asked Questions
Where can I buy MULTICOMP PRO SBR2512W?
You can click on the BUY or RFQ button to purchase SBR2512W from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part SBR2512W?
You can download the SBR2512W datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of SBR2512W?
MULTICOMP PRO
