MULTICOMP PRO SBR3510 Three Phase Bridge Rectifier
This three-phase bridge rectifier features silicon passivation, diffused junctions, low forward voltage drop, and high current capability. Designed for reliable operation in industrial power conversion, it supports high surge currents and is ideal for printed circuit board applications. Encased in an epoxy case with a heat sink, it offers excellent thermal management and durability. Suitable for applications requiring high voltage and current ratings, it ensures efficient rectification with low power loss and robust electrical performance for demanding industrial environments.
MULTICOMP PRO SBR3510 Three Phase Bridge Rectifier Specifications:
- Maximum Forward Voltage drop per element: 12 V at 12.5A/17.5A peak
- Peak Repetitive Voltage VRRM: 50V to 1600V
- Working Peak Reverse Voltage VRWM: 50V to 1600V
- Peak Non-Repetitive Reverse Voltage VrsM: 75V to 1700V
- RMS Reverse Voltage: 35V to 1120V
- Maximum Average Forward Rectified Current: 35A
- Non-Repetitive Peak Forward Surge Current: 500A
- DC Blocking Voltage: up to 1600V
- Thermal Resistance Junction to Case: 1.16 kW
- Storage Temperature Range: -55°C to +160°C
- Operating Temperature Range: -55°C to +160°C
- Peak Forward Voltage: 12V at 12.5A/17.5A
- Isolation Voltage from Case to Lead: 2,500V
- Dimensions: Diameter approximately 49.1mm (1.93 inches), thickness approximately 22mm (0.87 inches), heat sink compatible.
Buy the Multicomp Series SBR3510 Three Phase Bridge Rectifier: SBR3510
Order the high-capacity three-phase bridge rectifier from multicomp online today and ensure reliable power management for your industrial projects. Designed for high surge currents and operational robustness, it provides low forward voltage drop and efficient rectification, making it suitable for demanding environments. Its epoxy case with a heat sink ensures optimal thermal performance and long durability. Whether for new installations or replacements, this rectifier guarantees stable operation, excellent electrical characteristics, and easy mounting for industrial power conversion systems.
Buy multicomp three phase bridge rectifier now and experience unmatched reliability and performance in high-current industrial power systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO SBR3510?
You can click on the BUY or RFQ button to purchase SBR3510 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part SBR3510?
You can download the SBR3510 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of SBR3510?
MULTICOMP PRO
