MULTICOMP PRO SBR3514 Three Phase Bridge Rectifier
This three-phase bridge rectifier features silicon passivation, diffused junctions, and low forward voltage drop, making it ideal for high-current industrial applications. Designed with a robust epoxy case and heat sink mounting, it ensures high reliability and surge current capacity. Suitable for printed circuit boards, it supports resistive, inductive, and capacitive loads with a maximum non-repetitive surge current of 450A. Operating over -55°C to +160°C with thermal resistance optimized for efficient heat transfer, it delivers consistent performance in demanding environments. Its high surge capacity and low forward voltage make it perfect for power rectification systems.
MULTICOMP PRO SBR3514 Three Phase Bridge Rectifier Specifications:
- Peak Repetitive Voltage VRRM: 50-1600 V
- Working Peak Reverse Voltage VRWM: 50-1600 V
- DC Blocking Voltage VR: 75-1700 V
- Peak Non-Repetitive Reverse Voltage VrsM: 75-1700 V
- Maximum Average Forward Rectified Current: 35A
- Non-Repetitive Peak Forward Surge Current: 500A
- Maximum Forward Voltage Drop at 12.5A: 12V
- Peak Reverse Current @ 25°C: 10 pA
- Thermal Resistance Junction to Case: 1.16 kW
- Thermal Resistance Case to Heatsink: 0.2 K/W
- Operating Temperature Range: -55°C to +160°C
- Isolation Voltage from Case to Lead: 2,500 V
- Dimensions: Diameter approximately 24.9 mm (0.98 inches), with detailed mounting measurements provided
- Encapsulation: Epoxy case with heat sink mounting surface
- Mounting: Bolt down on heatsink with thermal compound, torque max 20 in-lb
- Weight: Approximately 20 grams
Buy the Multicomp Passivated Bridge Rectifier – Reliable Power Conversion for Industrial Applications
Secure your power management needs with our three-phase bridge rectifier, designed for high current capacity, low forward voltage, and superior reliability. Easy to install with bolt-down mounting on heatsinks—perfect for industrial power supplies. Supports resistive, inductive, and capacitive loads with surge currents up to 450A. Operating temperature range from -55°C to +160°C ensures durability in harsh environments. Whether for rectification or power conversion, this silicon passivated rectifier offers consistent, efficient performance for demanding industrial applications.
Get multicomp passivated bridge rectifier today—built for high current and long-lasting durability in industrial power systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO SBR3514?
You can click on the BUY or RFQ button to purchase SBR3514 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part SBR3514?
You can download the SBR3514 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of SBR3514?
MULTICOMP PRO
