MULTICOMP PRO SIP06T Six-Channel SPST Switch
The SIP-06T is a single-pole single-throw switch with six channels, featuring solder terminals, gold-plated contacts over nickel, and a white nylon actuator. Its high-density, slim profile design allows for compact packaging, with splay terminals enabling automatic insertion via IC insertion machinery. The switch incorporates insert molding of terminals and ultrasonic welding for durability, along with a high-pressure contact structure that prevents vibration shocks. It supports a maximum contact resistance of 100 milliohms, insulation resistance of 100 megaohms at 500V DC, and a minimum dielectric strength of 300VAC for one minute, suitable for industrial automation and control systems.
MULTICOMP PRO SIP06T Six-Channel SPST Switch Specifications:
- Switching Rating: 5V DC at 100mA
- Carrying Rating: 50V DC at 100mA
- Initial Contact Resistance: 100 milliohms
- Insulation Resistance: 100 megaohms at 500V DC
- Dielectric Strength: 300VAC/minute
- Material: Nylon high-temperature thermoplastic
- Cover and Base Color: Black
- Actuator: White nylon thermoplastic
- Contact Plating: Gold over nickel
- Terminal: Tin/Lead solder
- Dimensions: Length 17.78mm (0.7 inch) for 6 channels, 22.86mm (0.9 inch) for 8 channels
- Operating Temperature: -30°C to +80°C
- Design Features: Splay terminals, ultrasonic welding, insert molding, high-pressure contact
Buy the Multicomp SIP06T – Reliable SPST Switch for Industrial Applications
Order the six-channel SPST switch from Multicomp Pro today for reliable, high-density switching in industrial automation systems. Featuring gold-plated contacts, easy-solder terminals, and a slim profile, this switch ensures durability and ease of assembly. Its high-pressure contact structure prevents vibration shock, making it suitable for demanding industrial environments. Automate your assembly process with splay terminals designed for IC insertion machines. Get this high-quality switch now to enhance control panel reliability and streamline your manufacturing workflow with fast shipping and excellent customer service.
Buy Multicomp SIP06T now and experience reliable performance with easy automated insertion and compact design for industrial controls.
Frequently Asked Questions
Where can I buy MULTICOMP PRO SIP06T?
You can click on the BUY or RFQ button to purchase SIP06T from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part SIP06T?
You can download the SIP06T datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of SIP06T?
MULTICOMP PRO
