MULTICOMP PRO FDD21878 Quick Disconnect Terminal
The FDD2-187(8) is a blue male quick disconnect terminal with vinyl insulation and brass/copper construction, designed for reliable electrical connections in industrial, communication, and networking applications. It features a double crimp with copper sleeve, easy cable entry, and an electro-tin-plated finish to prevent oxidation. Suitable for wire gauges 22-16 AWG, it offers a rated current of 10A and maximum electrical rating of 600V at 105°C. Certified to standards BS4579, IEC352-2, and ISO1996, this terminal ensures durability and safety.
MULTICOMP PRO FDD21878 Quick Disconnect Terminal Specifications:
- Insulation Material: Vinyl
- Color: Blue
- Terminal Material: Brass and Copper
- Rating Current: 10A
- Maximum Voltage: 600V at 105°C
- Wire Range: 22-16 AWG
- Temperature Range: -20°C to +85°C
- Certification: BS4579, IEC352-2, ISO1996
- Finish: Electro tin-plated
- Crimp Type: Double crimp with copper sleeve
- Compliance: BS6017 (1981), BS1872 (1984)
- Approximate Dimensions: W 0.197 inch, L 0.252 inch, D 0.413 inch
Buy the Buy Multicomp Pro Female Quick Disconnect Part Number FDD21878 Online
Purchase the Multicomp Pro FDD21878 quick disconnect terminal online today for reliable and efficient electrical connections. Its vinyl insulation and brass/copper construction ensure durability, while the double crimp design provides secure attachment to wires from 22 to 16 AWG. Certified to industry standards, it offers a maximum voltage of 600V and a rated current of 10A, suitable for industrial, communication, and networking use. Order now to benefit from fast delivery and consistent performance in your projects.
Buy Multicomp Pro FDD21878 now and experience reliable connections with easy crimping and corrosion resistance in industrial applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO FDD21878?
You can click on the BUY or RFQ button to purchase FDD21878 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part FDD21878?
You can download the FDD21878 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of FDD21878?
MULTICOMP PRO
