MULTICOMP MCAK207NBBWWP industrial waterproof keypad
The MCAK207NBBWWP is a durable waterproof 3x4 matrix keypad made of black plastic, ideal for industrial environments. It features 12 keys with white legends, IP67 protection, a maximum contact resistance of 200 milliohms, and a lifespan of 1,000,000 cycles per key. Operating conditions range from -20°C to 60°C, ensuring reliable performance in harsh settings. The keypad has standard dimensions with 56.2mm height, 72mm length, and a panel cutout of 51.2mm by 33.5mm. Its sturdy water-proof design and reliable contact technology make it suitable for automation, control panels, and machinery interfaces.
MULTICOMP MCAK207NBBWWP industrial waterproof keypad Specifications:
- Contact Rating: 20mA, 24V DC
- Max. Contact Resistance: 200 milliohms
- Life: 1,000,000 cycles per key
- Operating Temp.: -20°C to +60°C
- Storage Temp.: -40°C to +65°C
- Colour: Black
- Material: Plastic
- Waterproofing: IP67
- Keypad Array: 3x4 matrix
- Keypad Output: Matrix
- Panel Cutout Width: 51.2mm
- Panel Cutout Height: 33.5mm
- External Length / Height: 72mm / 56.2mm
- Fixing Centres Length x Width: 40.56mm
- Waterproof Rating: IP67
- Operating Force: 1.18N
- Travel: 2mm
- Actuating Force: 1.18N
- Stroke: 2mm
Buy the Multicomp MCAK207NBBWWP – Reliable Waterproof Keypad for Industrial Applications
Enhance your control systems with the waterproof black 3x4 matrix keypad designed for industrial use. Featuring 12 keys with a robust IP67 rating, it ensures resistance to dust and water. Perfect for automation, machinery, and control panels, this keypad operates reliably from -20°C to 60°C, with a lifespan of one million cycles per key. Its compact dimensions and standard matrix output make installation straightforward. Trust in the durability and quality of this rugged keypad to improve operational efficiency and safety in demanding environments.
Buy Multicomp MCAK207NBBWWP now and experience unmatched waterproof durability and reliable performance in harsh environments.
Frequently Asked Questions
Where can I buy MULTICOMP MCAK207NBBWWP?
You can click on the BUY or RFQ button to purchase MCAK207NBBWWP from an authorized MULTICOMP distributor.
How do I troubleshoot issues or seek technical support for part MCAK207NBBWWP?
You can download the MCAK207NBBWWP datasheet or visit the MULTICOMP website for support.
Who is the manufacturer of MCAK207NBBWWP?
MULTICOMP
