MULTICOMP MCPINT5S001 Inductive Proximity Sensor
The inductive proximity sensor features a compact M5 short housing with a 5mm diameter, designed for reliable metal detection. It operates on DC 10-30V with a 3-wire connection type, offering both shielded (1mm) and unshielded (2mm) mounting distances. Made of brass with chrome plating, it is resistant to oil, water, acids, and alkalis, with an IP67 protection rating for water resistance. Suitable for measuring, counting, and RPM detection in various industrial applications, including chemical and paper manufacturing, it includes over-current protection and an LED indicator for easy operation.
MULTICOMP MCPINT5S001 Inductive Proximity Sensor Specifications:
- Mounting Distance: 1mm shielded / 2mm unshielded
- Sensing Distance: Shielded (0-0.8mm) / -
- Power Supply: DC 10-30V
- Frequency: < 600Hz
- Current Output: 100mA
- Ambient Temperature: -20°C to +70°C
- Protection: Over-Current, Against Polarity
- IP Rating: IP67
- Construction Material: Brass chrome plated
- Protection against water, oil, acids, and alkalis
- Connection Type: 3-wire NPN or PNP
- Mounting options: shielded or unshielded
Buy the Buy Premier Farnell Inductive M5 Short Housing Sensor Part Number MCPINT5S001 Online
Purchase the Premier Farnell Inductive Proximity Sensor online today. Designed for reliable metal detection in industrial environments, it features a compact M5 short housing, operating on 10-30V DC with over-current protection, LED indicator, and water-resistant IP67 rating. Easy to install with both shielded and unshielded mounting distances, it’s suitable for measuring, counting, and RPM detection across chemical, paper, and light industry sectors. Ensure seamless operations with this durable, high-performance sensor available for quick online purchase.
Get Premier Farnell MCPINT5S001 today—built for precision with IP67 water resistance and versatile mounting options for industrial metal detection.
