MULTICOMP MCSKB08E Relay Socket for JQX Series
This relay socket is designed for easy installation and reliable connection with JQX series relays, providing a secure and safe electrical interface. Built for industrial automation, it supports a load voltage of 300V and nominal currents of 12A or 10A depending on the model. The socket features high dielectric strength between coil and contact at 4,000V and between contacts at 2,500V, ensuring safety and durability. It accommodates wire sizes 20~14 AWG and has a maximum tightening torque of 1Nm. Suitable for ambient temperatures from -45°C to +85°C, it weighs 50-56g.
MULTICOMP MCSKB08E Relay Socket for JQX Series Specifications:
- Part Number: MCSKB08-E, MCSKB14-E
- Nominal Current: 12A for MCSKB08-E, 10A for MCSKB14-E
- Load Voltage: 300V
- Dielectric Between coil and contact: 4,000V/S
- Dielectric Between contacts: 2,500V/S
- Max. Tightening torque: 1Nm
- External Connection Wire: 20~14 AWG, 0.5~2.5 mm²
- Ambient Temperature Range: -45°C to +85°C
- Weight: 50g (MCSKB08-E), 56g (MCSKB14-E)
Buy the Premier Farnell MCSKB08-E – Reliable Relay Socket for Industrial Applications
Order the Premier Farnell relay socket online today for seamless integration into your automation or control systems. Designed with high dielectric strength and compatible with various wire sizes, this relay socket ensures safe, reliable connections in demanding environments. Its robust construction supports load voltages up to 300V and currents of 12A or 10A, making it ideal for industrial applications. With easy installation and temperature tolerance from -45°C to +85°C, it guarantees durability and long-term performance, delivering value and peace of mind for your projects.
Buy Premier Farnell MCSKB08-E relay socket now and experience unmatched reliability and performance in industrial automation systems.
Frequently Asked Questions
Where can I buy MULTICOMP MCSKB08E?
You can click on the BUY or RFQ button to purchase MCSKB08E from an authorized MULTICOMP distributor.
How do I troubleshoot issues or seek technical support for part MCSKB08E?
You can download the MCSKB08E datasheet or visit the MULTICOMP website for support.
Who is the manufacturer of MCSKB08E?
MULTICOMP
