MULTICOMP SPC15131 High-Density D-Sub Connector
The SPC15131 is a 62-way D-sub connector designed for space- and weight-sensitive applications in industrial environments. It features gold-plated brass contacts for reliable connectivity and a glass-filled PBT insulator with UL94V-0 rating for high safety standards. The steel shell is tin-plated, providing durability and corrosion resistance. Supporting wire sizes from 24 to 20 AWG, it offers a maximum contact resistance of 15 miliohms, insulation resistance of at least 1000 megaohms, and can withstand 500 VAC for 1 minute. Suitable for various industrial and electronic applications, ensuring high performance and reliability.
MULTICOMP SPC15131 High-Density D-Sub Connector Specifications:
- Current Rating: 5 Amps
- Contact Resistance: 15 miliohms Max.
- Insulator Resistance: 1000 Megohms Min.
- Voltage: 500 VAC for 1 Minute
- Temperature Range: -50°C to +100°C
- Material: Steel shell, Tin plated; Insulator: PBT +30% Fiber Glass, Black, UL94V—0 Rated
- Contact Material: Brass, Gold-plated on Contact Area, Tin-plated on Solder Cup
- Connector Type: 62-way D-Sub Plug
- Wire Range: 24-20 AWG
Buy the Buy SPC Technology 62 Pin D-Sub Connector Part Number SPC15131 Online
Purchase the SPC15131 high-density 62-pin D-Sub connector online today to enjoy precise connectivity solutions for space- and weight-sensitive projects. Featuring gold-plated brass contacts, a durable steel shell, and an UL94V-0 rated glass-filled PBT insulator, this connector ensures high safety standards. It supports wire sizes from 24 to 20 AWG, provides a maximum contact resistance of 15 miliohms, and withstands 500 VAC for one minute. Ideal for industrial, electronic, and communication systems, delivering superior performance and reliability.
Buy SPC Technology SPC15131 now and experience reliable high-density connections optimized for industrial and electronic applications.
Frequently Asked Questions
Where can I buy MULTICOMP SPC15131?
You can click on the BUY or RFQ button to purchase SPC15131 from an authorized MULTICOMP distributor.
How do I troubleshoot issues or seek technical support for part SPC15131?
You can download the SPC15131 datasheet or visit the MULTICOMP website for support.
Who is the manufacturer of SPC15131?
MULTICOMP
