MULTICOMP SPC15349 D-Sub Connector
The SPC15349 is a 50-pin D-sub socket designed for reliable electronic connections in communication and networking equipment. It features machined brass contacts with 5 microinch gold plating over nickel, ensuring excellent conductivity and corrosion resistance. The housing is made of PBT and glass fiber reinforced for durability and stability. Rated for 5A current and capable of withstanding up to 1000V dielectric strength, it operates efficiently within a temperature range of -50°C to +105°C. Its solder termination makes installation straightforward, making it an ideal choice for rugged, high-performance electronic systems.
MULTICOMP SPC15349 D-Sub Connector Specifications:
- Shell: Steel, Tin-Plate
- Contact: Brass, 5 Micro Inch Gold-Plated over Nickel
- Housing: PBT & Glass-Fiber Reinforced
- Current Rating: 5 Amps
- Dielectric Strength: 1000 V for One Minute
- Insulator Resistance: 1000 Megohms Min. at 500 VDC
- Temperature Range: -50°C to +105°C
- Solder Termination: Yes
- Connector Type: 50-way D-sub
- RoHS: Compliant
- Dimensions: Length approximately 55.3 mm (2.177 inches), Width approximately 13.4 mm (0.528 inches)
Buy the SPC Series D-Sub Connector: SPC15349
Enhance your electronic connections with the SPC15349 50-pin D-sub socket, featuring gold-plated brass contacts and a durable PBT housing. This connector delivers excellent conductivity, corrosion resistance, and optimal performance across a wide temperature range. Its solder termination ensures secure installation, making it ideal for communications, industrial, and networking applications. Rated for 5A and with a dielectric strength of 1000V, it provides long-lasting, dependable service in demanding environments. Order online today for reliable connectivity solutions.
Buy SPC Series D-Sub Connector SPC15349 now and experience unmatched reliability and performance.
