MULTICOMP USBASRA USB 3.0 Receptacle
The USB-A-S-RA is a 4-position USB 3.0 receptacle with right-angle PCB mounting for compact electronic assemblies. It features gold flash over nickel-plated phosphor bronze contacts, a black PBT insulator, and a nickel-plated phosphor bronze shell. Rated for 1.5A at 250VAC and a voltage of 30VAC, it ensures reliable connections with a contact resistance of 30 milliohms and insulation resistance of at least 1000 megaohms at 500VDC. The connector withstands 500VAC dielectric voltage and operates effectively between -20°C and +60°C, making it suitable for computers, peripherals, and networking devices.
MULTICOMP USBASRA USB 3.0 Receptacle Specifications:
- RoHS Compliant
- Material: PBT insulator, Phosphor Bronze contacts and shell with Nickel Plating
- Contact Plating: Gold flash over Nickel underplate
- Voltage Rating: 30V AC
- Current Rating: 1.5A at 250V AC
- Contact Resistance: 30mΩ Max
- Insulation Resistance: ≥1000MΩ at 500V DC
- Dielectric Withstanding Voltage: 500V AC
- Operating Temperature Range: -20°C to +60°C
- Connector Type: USB 3.0, Type A, Receptacle, Single Port
- Mounting Type: Right-angle PCB mounting
- Shell Material: Phosphor Bronze, Nickel Plated
- Insulator Color: Black
- Overall Dimensions: As per datasheet (see layout diagram)
Buy the Buy Premier Farnell USB 3.0 Type A Receptacle Part Number USBASRA Online
Get the Premier Farnell USB 3.0 Receptacle with right-angle PCB mounting, gold-plated contacts, and durable construction. Perfect for computer, peripheral, and networking device assembly. Easy to install with high reliability, rated for 1.5A at 250VAC, and operating effectively from -20°C to +60°C. Designed with high-quality materials, including phosphor bronze shell and insulator, ensuring long-term performance and secure connections. Purchase now online to upgrade your device interfacing with top-tier USB connectors for professional electronic projects.
Order your Premier Farnell USB 3.0 Type A Receptacle USBASRA today and enhance your electronic projects with reliable, high-speed connectivity.
Frequently Asked Questions
Where can I buy MULTICOMP USBASRA?
You can click on the BUY or RFQ button to purchase USBASRA from an authorized MULTICOMP distributor.
How do I troubleshoot issues or seek technical support for part USBASRA?
You can download the USBASRA datasheet or visit the MULTICOMP website for support.
Who is the manufacturer of USBASRA?
MULTICOMP
