MURATA POWER SOLUTIONS DMS30PC420S24RSIC Digital Panel Meter
The DMS-30PC-4/20S-24RS-I-C is a 3.5-digit, standard-intensity red LED panel meter with an isolated power supply. It offers excellent electrical performance, high display readability, ease of use, and long-term reliability. Built with Murata Power Solutions' durable epoxy-encapsulated digital voltmeter, it features a gold-plated DIP switch for decimal point and range settings, eliminating the need for solder jumpers. Connections to the current loop and power supply are made via a rugged, 4-position screw terminal block. This user-friendly design supports numerous input and output configurations, reducing the need for custom factory modifications, especially in applications requiring multiple ranges. The entire assembly is soldered, features secure screw fasteners, and includes an EPDM rubber gasket for moisture and dust resistance. It is suitable for industrial, metering, and test & measurement applications. Please note, increased market demand may extend lead times, and pricing excludes discounts.
MURATA POWER SOLUTIONS DMS30PC420S24RSIC Digital Panel Meter Specifications:
- Display Type and Size: 3.5-digit, 0.56/1.42 mm high LED
- Input Range: +35 to -22 mA
- Input Impedance: 400 Ohms
- Voltage Drop: 20 Volts
- Overcurrent Protection: 2015 to 203 mA
- Accuracy: ±0.05% FS + 1 count
- Operating Temperature: 0°C to +50°C
- Storage Temperature: -40°C to +85°C
- Humidity: 0-95% non-condensing
- Power Supply Range: +4.75 to +5.25V at 225mA; +7.5 to +32V at 30mA
- Case Material: Polycarbonate
- Weight: 4 ounces (28 grams)
- Connection Terminals: 4-position screw-type terminal block
- Enclosure: Rugged epoxy-encapsulated construction with moisture/dust gasket
- Optional Bezel and Gasket Available
Buy the Murata 24RSIC – Reliable Industrial Panel Meter for Measurement Applications
Experience the reliability of Murata's digital panel meters by ordering the DMS-30PC-4/20S-24RS-I-C online today. Featuring a 3.5-digit LED display, isolated power supply, versatile input configurations, and durable epoxy-encapsulation, this meter ensures long-term performance in industrial environments. Its high accuracy, simple DIP switch settings, and rugged screw-terminal connections make installation and calibration straightforward. Perfect for industrial measurement, control panels, and test equipment, this meter offers excellent readability, moisture resistance, and flexibility. Order now for fast delivery and reliable operation in demanding applications.
Order your Murata Series DMS-30PC-4/20S-24RS-I-C today and give your projects the dependable quality they deserve, thanks to its high-accuracy and robust design.
