Murata LQH44PH221MPRL Ceramic Inductor
The LQH44PH221MPRL is a compact multilayer ceramic inductor designed for high-performance electronic applications. Featuring a size of 4040 (Inch: 1515) mm with a maximum thickness of 1.8mm, it offers a high inductance of 220H with a tolerance of ±20%. Its low DC resistance and stable inductance at high frequencies make it suitable for power supplies, DC/DC converters, and RF circuits. The component is shielded by a magnetic resin, operates within a temperature range of 40°C to 125°C, and is tested at a frequency of 100kHz for 330mA rated current.
Murata LQH44PH221MPRL Ceramic Inductor Specifications:
- Size: 4.0 mm x 4.0 mm x 1.8 mm
- Inductance: 220H ±20%
- Test Frequency: 100kHz
- Rated Current: 330mA
- Max. DC Resistance: 3.78 Ω
- Operating Temperature Range: 40°C to 125°C
- Self-Resonance Frequency: 4 MHz
- Material: Magnetic Resin shielding
- Temperature Rise at Rated Current: Max 40°C (ambient 85°C)
- Series: LQH44PH_PR
Buy the Murata LQH44PH221MPR – Reliable Ceramic Inductor for Industrial Applications
Enhance your electronic designs with the Murata LQH44PH221MPR ceramic inductor. Combining compact size, high inductance of 220H, and low resistance, it ensures excellent performance in power supplies and RF circuits. Its magnetic resin shield offers added stability, while operating within a wide temperature range of 40°C to 125°C. This reliable, helical inductor is tested at 100kHz for a rated current of 330mA, making it an essential component for engineers seeking durability and consistency in demanding environments.
Get Murata LQH44PH221MPR today—built for precision and long-lasting durability in power and RF circuits.
Frequently Asked Questions
Where can I buy Murata LQH44PH221MPRL?
You can click on the BUY or RFQ button to purchase LQH44PH221MPRL from an authorized Murata distributor.
How do I troubleshoot issues or seek technical support for part LQH44PH221MPRL?
You can download the LQH44PH221MPRL datasheet or visit the Murata website for support.
Who is the manufacturer of LQH44PH221MPRL?
Murata
