MYRRA 48023 Compact Power Module
The 1W to 3W power supply offers a compact, PCB-mount design suitable for various applications, with a single output range from 3.3VDC to 24VDC and input voltages from 85VAC to 265VAC or 120VDC to 370VDC. Features include very low standby power consumption below 0.15W, high energy efficiency meeting Energy Star and EC Standards, encapsulated construction, and a footprint similar to an EE20 transformer for easy upgrades. Its safety and EMC compliance ensure reliable performance in diverse environments, making it an ideal choice for tight spaces requiring efficient and safe power conversion.
MYRRA 48023 Compact Power Module Specifications:
- Output Range: 3.3VDC - 24VDC
- Input Voltage Range: 85VAC - 265VAC / 47 - 63Hz or 120VDC - 370VDC
- Power Rating: 1W to 3W
- Standby Power Consumption: < 0.15W
- Dimensions: Similar footprint as EE20 transformer, size not specified
- Protection: Output short circuit protection, over temperature shutdown at 140°C
- Efficiency: Meets Energy Star & EC Code of Conduct requirements
- Safety Standards: IEC/EN61558-2-16, IEC/EN60950, IEC/EN60335, UL/CUL60950, CE, VDE, ENEC
- EMC Compliance: EN55014 Class B, EN55032 Class B, FCC Part 15
- Operating Temperature: -25°C to +85°C
- Storage Temperature: -40°C to +85°C
- Insulation: Primary to secondary 4000Vac
- MTBF: Over 200,000 hours at 230VAC
- Weight: About 16 grams per unit
Buy the Universal Series Power Supply: 1W to 3W Compact Power Module
Discover the reliable, energy-efficient power solution perfect for your compact electronic devices. This power module offers a wide input range, low standby power, and high safety standards, optimized for tight spaces. Its encapsulated design simplifies upgrading existing systems without redesigning PCBs. With proven EMC compliance and robust protection features, it guarantees safe, stable operation across various industrial and commercial applications. Purchase online today and experience seamless integration and dependable performance for your power needs.
Get Universal Series Power Supply today—built for precision and long-lasting durability in space-constrained environments.
