Microchip Technology HV56020TVKXX High Voltage Power Module
The HV56020 is a versatile multi-chip module designed for high-voltage haptic and power applications. It combines dual high voltage operational amplifiers capable of up to +225V, a DC-to-DC step-up converter, and a power MOSFET for efficient voltage generation. The device includes advanced protection features like over/undervoltage, short circuit detection, and temperature sensing. Its integrated 24 MHz SPI interface facilitates precise control and monitoring, making it ideal for driving piezo actuators, power amplifiers, and other high-voltage electronic systems requiring reliable and compact performance.
Microchip Technology HV56020TVKXX High Voltage Power Module Specifications:
- Maximum voltage: +225V for high voltage op amps
- Output current: 40mA minimum
- Bandwidth: 124Hz, -3dB at 0.22uF load
- DC to DC step-up converter with adjustable output via SPI
- Input voltage supply: 2.7V to 5.5V
- Power MOSFET: 60V BVdss, 10 mΩ Rds(on), 14nC gate charge
- Protection features: Over/Undervoltage, Short circuit, Temperature sensor
- Operating temperature range: 0°C to +125°C
- Package: 43-Lead VQFN, 7mm x 7mm
- Includes a 24MHz SPI interface for control
- Preload capacitors recommended: 10 nF for amplifiers, 2 uF for charge pump
- Thermal resistance from silicon to PCB: minimized via copper pours and via connections
- Designed for haptic drivers and high-voltage power amplification
