Microchip Technology MCP3562EST 24-Bit Delta-Sigma ADC
The MCP3562 is a high-precision, multi-channel 24-bit Delta-Sigma ADC with configurable data rates up to 153.6 ksps, integrated temperature sensor, low noise, and secure SPI interface, ideal for industrial, automation, and measurement applications. It supports differential or single-ended inputs, programmable gain from 0.33x to 64x, internal calibration, and advanced security features, all within compact packages and extended temperature range, suitable for demanding environments requiring accuracy and reliability.
Microchip Technology MCP3562EST 24-Bit Delta-Sigma ADC Specifications:
- Resolution: 24-bit
- Data Rate: Up to 153.6 ksps
- Input Channels: 2 (MCP3562) with differential or single-ended configuration
- Gain Range: 0.33x to 64x programmable
- Reference Voltage: Differential inputs with internal/external references
- Power Supply: AVpp 2.7V to 3.6V, DVpp 1.8V to 3.6V
- Input Voltage Range: OV to AVpp
- Input Impedance: Proportional to internal sampling capacitor, varies with gain
- Input Current Leakage: <10 nA typical
- Temperature Range: -40°C to +125°C
- Package: 20-lead UQFN (3x3 mm), 20-lead TSSOP (6.4x6.4 mm)
- Features: Internal temperature sensor, burnout detection, CRC security, 20 MHz SPI interface, lock/unlock register map, digital offset & gain calibration, automatic sequencer
- Power Consumption: <2.2 mA in normal operation, ultra-low power shutdown modes
- Additional: Embedded digital filters, configurable decimation, external or internal clock for flexible synchronization
Buy the Microchip Series MCP3562 ADC: 24-Bit Delta-Sigma 2-Channel, 153.6 ksps, Low Noise
Order the Microchip MCP3562 today and experience high-precision, multi-channel data acquisition with configurable gain, integrated temperature sensor, and secure SPI communication. Designed for demanding industrial, automation, and measurement solutions, its compact package and extended temperature range ensure reliable operation in harsh environments. With advanced security features, internal calibration, and configurable data rates up to 153.6 ksps, this ADC provides exceptional accuracy and low noise. Perfect for portable instrumentation, factory automation, and precision sensors—order now for optimal system performance.
Get Microchip MCP3562 today—built for precision, security, and reliable high-speed data acquisition in industrial and portable measurement applications.
Frequently Asked Questions
Where can I buy Microchip Technology MCP3562EST?
You can click on the BUY or RFQ button to purchase MCP3562EST from an authorized Microchip Technology distributor.
How do I troubleshoot issues or seek technical support for part MCP3562EST?
You can download the MCP3562EST datasheet or visit the Microchip Technology website for support.
Who is the manufacturer of MCP3562EST?
Microchip Technology
