Microchip Technology TC4452VAT High-Speed MOSFET Driver
The TC4452VAT is a high-speed MOSFET driver designed for driving large MOSFETs and IGBTs with high peak currents up to 13A. It features matched rise and fall times of 21 ns with 10,000 pF load and 42 ns with 22,000 pF load, wide operating voltage range of 4.5V to 18V, and low supply current of 140 pA logic ‘1’ input. Its space-saving 8-pin DFN package provides robust protection against electrostatic discharge and reverse currents up to 1.5A, making it ideal for line drivers, pulse generators, motor controls, and power switching applications.
Microchip Technology TC4452VAT High-Speed MOSFET Driver Specifications:
- Supply Voltage: 4.5V to 18V
- Peak Output Current: 13A
- Continuous Output Current: 2.64A (max)
- Rise/Fall Time: 21 ns / 42 ns with 10,000 pF / 22,000 pF load
- Propagation Delay: 44 ns (typical)
- Input Voltage Range: TTL/CMOS compatible, up to 18V
- Input hysteresis: 300 mV
- Low supply current: 140 pA (logic high), 40 pA (logic low)
- Output impedance: 0.99Ω (typical)
- Reverse current withstand: 1.5A
- ESD protection: up to 4.0 kV (HBM), 400V (MM)
- Package: 8-pin DFN-S, space-saving with thermal pad
- Operating Temperature Range: -40°C to +125°C
- Thermal Resistance (DFN-S): 35.7°C/W
- Includes overvoltage and over-dissipation immunity
- Designed for driving high-capacitance loads in industrial and power switching applications
Buy the Microchip Series TC4452 High-Speed MOSFET Driver: TC4452VAT
Experience reliable power switching with the Microchip TC4452VAT high-speed MOSFET driver, capable of delivering 13A peak current and supporting wide voltage ranges from 4.5V to 18V. Its matched rise and fall times ensure minimal switching loss, suitable for line drivers, motor control, and pulse generating circuits. This space-efficient 8-pin DFN package features robust ESD protection, reverse current withstand, and thermally optimized design, making it ideal for industrial automation, power management, and high-capacitance loads. Buy online today for high performance and durability in demanding applications.
Get Microchip TC4452VAT today—built for precision and long-lasting durability in high-current switching applications.
Frequently Asked Questions
Where can I buy Microchip Technology TC4452VAT?
You can click on the BUY or RFQ button to purchase TC4452VAT from an authorized Microchip Technology distributor.
How do I troubleshoot issues or seek technical support for part TC4452VAT?
You can download the TC4452VAT datasheet or visit the Microchip Technology website for support.
Who is the manufacturer of TC4452VAT?
Microchip Technology
