NKK Switches A15JP Subminiature Toggle Switch
Subminiature toggle switch designed for precise control in compact electronic applications. It features a small form factor suitable for tight spaces and reliable switching performance.
NKK Switches A15JP Subminiature Toggle Switch Specifications:
- Electrical Capacity: 0.4VA maximum @ 28V AC/DC
- Contact Resistance: 50 milliohms maximum
- Insulation Resistance: 500 megohms minimum @ 500V DC
- Dielectric Strength: 500V AC contact-to-contact and contact-to-case for 1 minute
- Mechanical Life: 100,000 operations minimum for certain circuits
- Electrical Life: 50,000 operations minimum
- Operating Force: 1.47N (momentary); 1.18N (maintained) for .394" toggle
- Materials: Glass fiber reinforced polyamide, nickel plated brass, phosphor bronze with gold plating
- Temperature Range: -30°C to +85°C
- Humidity Resistance: 95% for 240 hours @ 40°C
- Soldering: Wave and manual soldering recommended
Buy the NKK Series A Process Sealed Subminiature Toggle Switch: A15JP
Experience the reliability and space-saving design of the Subminiature Toggle Switch. Perfect for compact electronic circuits, it offers precise control, durable construction, and seamless soldering. Ideal for low-voltage, low-current applications where space is limited but performance cannot be compromised. Elevate your electronic projects with this high-quality toggle switch that ensures long-term performance and stability. Purchase online now and enjoy quick delivery, easy installation, and dependable operation in all your automation and control systems.
Get NKK A15JP today—built for precision, space-saving control, and long-lasting durability in electronic switching applications.
Frequently Asked Questions
Where can I buy NKK Switches A15JP?
You can click on the BUY or RFQ button to purchase A15JP from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part A15JP?
You can download the A15JP datasheet or visit the NKK Switches website for support.
Who is the manufacturer of A15JP?
NKK Switches
