NKK Switches AS12CW Subminiature Slide Switch
This subminiature slide switch is engineered for space-saving in compact electronic devices. It features a smooth, positive detent actuation with enhanced contact stability and reliable logic-level performance. Its antistatic superstructure prevents static discharge, ensuring contact integrity. The switch has a 0.4VA maximum resistive load at 28V AC/DC, with a minimum of 50,000 operations. Constructed with glass fiber reinforced polyamide and phosphor bronze contacts, it is rated from -30°C to +85°C, making it suitable for low-voltage, low-current logic circuits with excellent durability and environmental resistance.
NKK Switches AS12CW Subminiature Slide Switch Specifications:
- Electrical Capacity: 0.4VA maximum @ 28V AC/DC maximum
- Contact Resistance: 50 milliohms maximum
- Insulation Resistance: 500 megohms minimum @ 500V DC
- Dielectric Strength: 500V AC minimum for 1 minute
- Mechanical Life: 50,000 operations minimum
- Actuator Travel: Pretravel 0.082 inches (2.1mm); Overtravel 0.016 inches (0.4mm); Total Travel 0.098 inches (2.5mm)
- Material: Glass fiber reinforced polyamide, carbon blended polyacetal
- Contact Material: Tin plated phosphor bronze, gold plated phosphor bronze or brass
- Operating Temperature Range: -30°C to +85°C
- Environmental Resistance: 90-95% humidity for 192 hours at 40°C
- Vibration Resistance: 10-60Hz with 1.5mm amplitude, lateral shocks 50G
- Soldering: Wave soldering recommended, manual soldering profiles provided
- Certification: Not UL or CSA tested, designed for low-voltage logic circuits
Buy the NKK Series AS Subminiature Slide Switch: AS12CW
Buy your NKK Series AS12CW subminiature slide switch online today. This space-efficient switch delivers dependable performance in low-voltage, low-current circuits. Its robust construction with antistatic features, high durability with 50,000+ operations, and environmental resistance make it perfect for compact electronic devices. Easy to solder and assembly-ready, the switch ensures consistent, reliable switching for sensitive logic-level applications. Enhance your projects with this high-quality switch that combines small size with proven reliability, available now for immediate purchase online.
Order your NKK Series AS12CW compact slide switch today and give your electronic projects reliable, space-saving control with durable contacts.
Frequently Asked Questions
Where can I buy NKK Switches AS12CW?
You can click on the BUY or RFQ button to purchase AS12CW from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part AS12CW?
You can download the AS12CW datasheet or visit the NKK Switches website for support.
Who is the manufacturer of AS12CW?
NKK Switches
