NKK Switches DB2511H Light Touch Miniature Pushbutton Switches
The light touch miniature pushbutton switches are engineered for precise, reliable actuation in compact electronic and industrial devices. Featuring smooth, long-lasting mechanical action with snap contacts, they provide tactile feedback and short stroke. Available with PCB or panel mounting, these switches are constructed from corrosion-resistant stainless steel frames, gold-plated contacts, and molded terminals to prevent contamination. They are rated for low-voltage, low-current circuits, with high contact resistance and insulation resistance, making them ideal for logic-level applications in diverse environments withstanding Vibration, humidity, and shocks. Suitable for many control and automation systems, they ensure durability and consistent performance over extensive cycle life.
NKK Switches DB2511H Light Touch Miniature Pushbutton Switches Specifications:
- Electrical Capacity: 0.4VA max @ 28V AC/DC, Resistive load
- Contact Resistance: 50 milliohms max
- Insulation Resistance: 1,000 megohms min @ 500V DC
- Dielectric Strength: 1,000V AC min for 1 min; 1,500V AC min between contacts & case
- Electrical Life: 200,000 operations min
- Mechanical Life: 100,000 operations min
- Operating Temp Range: -10°C to +70°C
- Humidity: 90-95% @ 40°C for 96 hours
- Vibration: 10-55Hz, peak-to-peak 1.5mm in 1 min
- Shock: 50G acceleration in all directions
- Mounting Torque: 1.47Nm double nut; 0.68Nm single nut
- Travel: Pretravel 0.020” (0.5mm); Overtravel 0.020” (0.5mm); Total Travel 0.039” (1.0mm)
- Materials: Brass with nickel plating (plunger and bushing), Stainless steel (frame), Glass fiber reinforced polyamide (case), Gold-plated copper (contacts).
- Dimensions: Cap diameters of 8.0mm and 10.0mm; terminal spacing 2.54mm; various mounting options with brackets and right-angle configurations.
- Soldering: Wave and manual soldering recommended; hand cleaning with alcohol-based solutions.
- Standards & Certifications: Not UL or CSA certified; designed for low-voltage applications.
Buy the NKK Series DB – Reliable Miniature Pushbuttons for Industrial Applications
Purchase NKK Series DB miniature pushbuttons online today for your electronic or industrial control projects. These switches offer durable construction, responsive tactile feedback, and long cycle life. They are easy to install with various mounting options, including PCB, panel, and bracket mounting. Whether used in consumer electronics or automation systems, these reliable switches ensure consistent performance. Enjoy quick delivery, secure online shopping, and technical support to enhance your equipment’s reliability and efficiency with these superior switches designed for demanding applications.
Buy NKK Series DB miniature pushbuttons now and experience unmatched reliability and performance in compact electronic controls.
Frequently Asked Questions
Where can I buy NKK Switches DB2511H?
You can click on the BUY or RFQ button to purchase DB2511H from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part DB2511H?
You can download the DB2511H datasheet or visit the NKK Switches website for support.
Who is the manufacturer of DB2511H?
NKK Switches
