NKK Switches JB15KP2G Tactile Switch
The low-profile tactile switch is ideal for PCB applications, providing dependable tactile feedback and long operational life in a compact, sealed design. It features a sealed rubber contact construction with snap-on caps for easy assembly and cleaning. The switch supports high and low operating forces, with options for flat, sculptured, or extended actuators, and conforms to industry standards for vibration, shock, and sealing. Suitable for various electronic devices requiring reliable, low-voltage, low-current switching in tight spaces.
NKK Switches JB15KP2G Tactile Switch Specifications:
- Electrical Capacity (Resistive Load): 50mA @ 24V DC for Standard Force, 125mA @ 24V DC for High Force
- Contact Resistance: 50 milliohms maximum
- Insulation Resistance: 500 megohms minimum @ 250V DC
- Dielectric Strength: 250V AC minimum for 1 minute
- Mechanical Life: 5,000,000 operations
- Electrical Life: 5,000,000 operations
- Nominal Operating Force: 1.76N for JB15, 2.65N for JB1SH
- Total Travel: 0.010" (.250mm) or 0.012" (.300mm)
- Actuator Material: Glass fiber reinforced PBT, PBT, Polyacetal
- Case & Base Material: Glass fiber reinforced polyamide (UL94V-0)
- Seal: Nitrile butadiene rubber
- Terminal: Stainless steel, brass with silver plating, phosphor bronze
- Operating Temperature Range: 25°C to +70°C (-13°F to +158°F)
- Vibration Resistance: 10-55Hz, peak-to-peak amplitude 1.5mm
- Shock Resistance: 50G (490m/s²)
- Sealing: IP67 standard
- Soldering: Wave and manual soldering recommended, automated cleaning compatible
Buy the Buy NKK Series JB Low Profile Process Sealed Tactiles Part Number JB15KP2G Online
Enhance your electronic designs with the reliable NKK Series JB tactile switch, offering sealed construction, long operational life, and a variety of actuator options. Perfect for PCB applications demanding precise tactile feedback, this switch supports automated soldering and cleaning processes. Its sealed rubber contact prevents contamination, ensuring durability in industrial environments. With high and low operating force options, it caters to diverse needs in automation, consumer electronics, and control systems, delivering dependable performance and easy assembly for quality-conscious engineers and manufacturers.
Order your NKK Series JB JB15KP2G tactile switch today and enjoy dependable, sealed operation with long-lasting performance for your electronic projects.
