NKK Switches JF15SP4C Tactile Push-Button Switch
The Ultra-Thin Tactile Push-Button Switch is designed for PCB mounting in compact electronic devices, featuring a low-profile of just 5mm. It offers crisp tactile feedback, high reliability, and long mechanical life with minimal operating force. Constructed with durable materials like polyamide and phosphor bronze contacts, it withstands harsh environments and is suitable for low-voltage, low-current circuits. The switch includes a rubber seal to prevent contact contamination, supports automated soldering and cleaning, and comes in various shapes, colors, and actuator types for versatile applications.
NKK Switches JF15SP4C Tactile Push-Button Switch Specifications:
- Electrical Capacity: 50mA @ 24V DC
- Contact Resistance: 50 milliohms maximum
- Insulation Resistance: 500 megohms minimum @ 250V DC
- Dielectric Strength: 250V AC for 1 minute
- Mechanical Life: 500,000 operations minimum
- Nominal Operating Force: 1.96N for sculptured, 2.0N for piano, 3.0N for square & round flush actuators
- Total Travel: 0.016” (0.4mm) for flush, 0.031” (0.8mm) for sculptured & piano actuators
- Operating Temperature Range: 25°C to +85°C
- Humidity: 90-95% for 96 hours @ 40°C
- Vibration: 10-55Hz, peak-to-peak amplitude 1.5mm, 2 hours per axis
- Shock: 50G in 6 directions, 5 shocks each
- Soldering: Wave and manual soldering compatible, automated cleaning recommended
- Materials: Actuator - Polyamide; Case - Glass fiber reinforced polyamide; Seal - Nitrile rubber; Terminals - Phosphor bronze with silver plating
Buy the Buy NKK Ultra-Thin Process Sealed Tactiles Part Number JF15SP4C Online
Experience reliable performance with the NKK Tactile Push-Button Switch designed for high-density PCB applications. Its ultra-thin profile, durable construction, and multiple actuator options provide excellent tactile feedback and long-lasting operation. Perfect for compact electronic devices, the switch supports automated soldering and cleaning, ensuring high-quality assembly. Suitable for low-voltage circuits, it features a rubber seal to prevent contamination and maintain reliability. Order online now to enhance your electronic projects with this versatile, durable switch that's quick to install and built for long-term use.
Get NKK JF15SP4C today—built for precise actuation, durability, and compact electronic applications.
Frequently Asked Questions
Where can I buy NKK Switches JF15SP4C?
You can click on the BUY or RFQ button to purchase JF15SP4C from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part JF15SP4C?
You can download the JF15SP4C datasheet or visit the NKK Switches website for support.
Who is the manufacturer of JF15SP4C?
NKK Switches
