NKK Switches LP0115CCKW015DB Illuminated Pushbutton Switch
This illuminated pushbutton switch offers reliable operation with bright LED illumination options in red, green, or amber. It features a compact short body design measuring 0.551 inches (14.0mm) to conserve behind-panel space, making it ideal for control panels and interface applications. The switch includes a snap-action contact mechanism with arc barrier protection, a robust polycarbonate housing, and easy mounting options like bushing or snap-in types. The switch operates within a temperature range of 10°C to +50°C with a lifespan of at least 500,000 operations for circuit durability and safety, meeting UL and cUL standards.
NKK Switches LP0115CCKW015DB Illuminated Pushbutton Switch Specifications:
- Electrical Capacity: 3A @ 125V AC/250V AC; 3A @ 30V DC
- Contact Resistance: 50 milliohms maximum
- Insulation Resistance: 200 megohms minimum @ 500V DC
- Dielectric Strength: 1000V AC between contacts, 1500V AC between contacts and case for 1 minute
- Mechanical Life: 500,000 operations minimum
- Electrical Life: 50,000 operations at 3A @ 125V/250V AC & 3A @ 30V DC; 100,000 at 1A
- Operating Temperature Range: 10°C to +50°C
- Travel: Total travel of 0.118 inches (3.0mm) with nonshorting contact mechanism
- Materials & Finishes: Actuator of polycarbonate, housing of UL94V-0 polyamide or polyphenylene ether, contact materials of phosphor bronze with silver or tin plating
- Mounting Types: Bushing mount with brass hex nut or snap-in mount with body finishes
- LED Colors: Red, Green, Amber with specified forward voltage and current
Buy the NKK 015DB – Reliable Control Button for Industrial Applications
Purchase the NKK Series LP0115CCKW015DB illuminated pushbutton switch online today for reliable control in industrial environments. Featuring bright LED illumination in red, green, or amber, this compact switch with a short body design of 0.551 inches conserves behind-panel space. It offers robust construction with polycarbonate housing, a snap-action contact mechanism, and compliance with UL and cUL certifications. Ideal for control panels and interfaces, it ensures durability up to 500,000 cycles and operates within a temperature range of 10°C to +50°C. Secure yours now for dependable performance in critical applications.
Order your NKK Series LP0115CCKW015DB illuminated pushbutton today and equip your control panels with a durable, space-saving, and easy-to-operate switch.
Frequently Asked Questions
Where can I buy NKK Switches LP0115CCKW015DB?
You can click on the BUY or RFQ button to purchase LP0115CCKW015DB from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part LP0115CCKW015DB?
You can download the LP0115CCKW015DB datasheet or visit the NKK Switches website for support.
Who is the manufacturer of LP0115CCKW015DB?
NKK Switches
