NKK Switches LP0125CMKW01C Illuminated Pushbutton
This short panel-mounted pushbutton switch features built-in LED illumination in red, green, or amber, with a durable polycarbonate cap and high-quality phosphor bronze contacts. Designed for reliable operation in industrial control systems, it offers easy mounting options including bushing and snap-in types, with a compact body conserving panel space. It supports resistive loads up to 3A at 125V AC or 30V DC, with a mechanical life of 500,000 operations, making it ideal for demanding electronic control and automation applications. Its environmental resistance ensures long-term performance in various conditions, complying with UL standards.
NKK Switches LP0125CMKW01C Illuminated Pushbutton Specifications:
- Power Rating: 3A @ 125V AC / 250V AC, 3A @ 30V DC
- Contact Resistance: 50 milliohms maximum
- Insulation Resistance: 200 megohms minimum @ 500V DC
- Dielectric Strength: 1,000V AC minimum between contacts; 1,500V AC minimum between contacts and case
- Mechanical Life: 500,000 operations minimum
- Electrical Life: 50,000 operations at 3A @ 125V/250V AC; 100,000 at 1A
- Nominal Operating Force: 1.5N for single pole, 3.0N for double pole
- Total Travel: 0.118 inches (3.0mm)
- Actuator Material: Polycarbonate
- Housing: UL94V-0 polyamide with UL recognition
- Mounting Types: Bushing and snap-in
- Panel Thickness: 0.079” to 0.256” (2.0mm to 6.5mm)
- Temperature Range: -10°C to +50°C (Illuminated), -25°C to +70°C (Non-illuminated)
- Environmental Resistance: 90-95% humidity for 240 hours, vibration, shock tested
- Standards & Certifications: UL, cUL recognized, Flammability UL 94V-0
- LED Voltage: Forward voltage approximately 2V, current 20mA
Buy the NKK LP0125CMKW01C – Reliable Illuminated Pushbutton for Industrial Applications
Enhance your control panels with the NKK illuminated pushbutton switch, featuring bright LED illumination in red, green, or amber. Its compact body design saves space, while the robust polycarbonate cap and high-quality contacts ensure long-lasting performance in industrial environments. Suitable for resistive loads up to 3A at 125V AC or 30V DC, it offers excellent electrical and mechanical durability, with environmental resistance complying with UL standards. Perfect for automation, machinery, and control systems needing reliable, easy-to-operate switching solutions.
Buy NKK LP0125CMKW01C now and experience unmatched reliability and performance with durable illumination and precise actuation.
Frequently Asked Questions
Where can I buy NKK Switches LP0125CMKW01C?
You can click on the BUY or RFQ button to purchase LP0125CMKW01C from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part LP0125CMKW01C?
You can download the LP0125CMKW01C datasheet or visit the NKK Switches website for support.
Who is the manufacturer of LP0125CMKW01C?
NKK Switches
