NKK Switches UB15NKG015F Low-Profile Pushbutton Switch
A low-profile illuminated pushbutton switch designed for PCB mounting and soldering applications. Suitable for various electronic devices requiring easy actuation with visual indication. It features a compact design, full face or spot illumination options with bright LEDs in multiple colors, and durable materials including polycarbonate caps. The switch supports quick-make, quick-break operation, with high electrical and mechanical life ratings, ideal for industrial control, automation, and equipment requiring reliable, space-saving switches with visual feedback.
NKK Switches UB15NKG015F Low-Profile Pushbutton Switch Specifications:
- Poles & Circuits: Single Pole, SPDT
- Maximum Electrical Capacity: 5A @ 125/250V AC, 0.4VA @ 28V AC/DC
- Contact Resistance: 50 milliohms for silver, 100 milliohms for gold
- Insulation Resistance: 200 megohms minimum @ 500V DC
- Dielectric Strength: 1,000V AC between contacts for 1 minute
- Mechanical Life: Minimum 1,000,000 operations
- Electrical Life: 200,000 operations
- Nominal Operating Force: 1.9N for single pole, 2.55N to 3.1N for double pole
- Travel: Total 0.091 inches (2.3mm), Pretravel 0.067 inches (1.7mm), Overtravel 0.024 inches (0.6mm)
- Housing: Glass fiber reinforced polyamide (UL94V-0)
- Cap Materials & Finishes: Polycarbonate, Glossy or Matte Finish, with various LED and color options
- Operating Temperature: -20°C to +70°C for non-illuminated, -25°C to +50°C for illuminated versions
- Certifications: UL recognition, CSA certification (order-specific)
Buy the NKK Series UB15NKG015F Low-Profile Pushbutton Switch: Reliable Industrial Control
Upgrade your control systems with the reliable NKK Series UB low-profile illuminated pushbutton switch. Featuring bright LED indicators in various colors, durable polycarbonate caps, and quick-make, quick-break contact operation, these switches are perfect for industrial automation, machinery, and control panels. With high electrical and mechanical life ratings and certified safety standards, you can trust this space-saving switch to deliver consistent performance. Purchase online today and ensure your projects benefit from proven quality and ease of installation.
Order your NKK Series UB low-profile illuminated pushbutton switch today and enhance your control panels with dependable, space-efficient operation.
Frequently Asked Questions
Where can I buy NKK Switches UB15NKG015F?
You can click on the BUY or RFQ button to purchase UB15NKG015F from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15NKG015F?
You can download the UB15NKG015F datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15NKG015F?
NKK Switches
