NKK Switches UB15SKG035D Illuminated Pushbutton
This low-profile illuminated pushbutton switch is ideal for compact electronic devices, offering reliable operation, easy PCB mounting with snap-in options, and colorful LED illumination. It features durable silver or gold-plated contacts, a rugged polyamide housing, and multiple illumination colors, including red, amber, green, and white. Designed for high switching capacity up to 5A at 125/250V AC, it supports quick actuation with an audible feedback mechanism. Its versatile design includes various cap styles, optional protective guards, and compliance with UL and CSA standards, making it suitable for industrial, automation, and control panel applications.
NKK Switches UB15SKG035D Illuminated Pushbutton Specifications:
- Electrical Capacity: 5A at 125/250V AC, 5A at 30V DC, 0.4VA max at 28V AC/DC
- Contact Resistance: 50 milliohms max (silver), 100 milliohms max (gold)
- Insulation Resistance: 200 megaohms minimum @ 500V DC
- Dielectric Strength: 1000V AC between contacts for 1 minute, 1500V AC between contacts and case
- Mechanical Life: 1,000,000 operations minimum for momentary, 200,000 for resistive load, 100,000 for silver contacts
- Electrical Life: 200,000 operations minimum for gold contacts
- Operating Temperature Range: -20°C to +70°C; -25°C to +50°C for illuminated models
- Contact Material: Silver alloy or copper, gold-plated
- Housing Material: Glass fiber reinforced polyamide (UL94V-0)
- Cap Colors & Types: Red, amber, green, white, with full face or spot illumination
- Switch Terminals: Solder lug, straight PC terminals
- Soldering Profile: Profile A (manual and wave soldering)
- Standards & Certifications: UL recognized, CSA certified when ordered with marking
- Mounting: Snap-in with panel thickness from 0.039" to 0.126"
Buy the NKK UB15SKG035D – Reliable Illuminated Pushbutton for Industrial Applications
Order the NKK UB15SKG035D illuminated pushbutton switch online today. This high-quality, low-profile switch offers durable contacts, vibrant LED illumination options, and easy PCB mounting. Perfect for control panels, automation, and industrial equipment, it supports high switching capacity up to 5A at 125/250V AC. Its compact design ensures seamless integration into tight spaces. Make your purchase now and enjoy fast delivery, reliable operation, and the confidence of UL and CSA certifications for your electronic and industrial projects.
Buy NKK UB15SKG035D now and experience unmatched reliability and performance in your control systems.
Frequently Asked Questions
Where can I buy NKK Switches UB15SKG035D?
You can click on the BUY or RFQ button to purchase UB15SKG035D from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15SKG035D?
You can download the UB15SKG035D datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15SKG035D?
NKK Switches
