NMB TECHNOLOGIES 3115PS12WB10A00 Axial Fan
This high-performance axial fan features a shaded pole induction motor with a durable aluminum casing and a polycarbonate impeller reinforced with glass fiber. Designed for reliable operation in various industrial cooling applications, it offers adjustable airflow up to 320 CFM, static pressure around 0.90 in H2O, and a temperature range from -10°C to +70°C. Compatible with AWG22 lead wires or Faston terminals, it ensures efficient heat dissipation and long operational life with a maintenance-free ball bearing system. Suitable for systems requiring quiet, steady air circulation with robust build quality.
NMB TECHNOLOGIES 3115PS12WB10A00 Axial Fan Specifications:
- Motor Structure: Shaded Pole Induction Motor
- Material: Aluminum casing, Polycarbonate impeller with glass fiber
- Bearing: Ball Bearing 169
- Lead Wire: AWG22, UL3266, CSACL1252 or Faston #110
- Operating Temperature Range: -10°C to +70°C
- Storage Temperature Range: -40°C to +70°C
- Dielectric Withstand Voltage: AC 700V 1s
- Insulation Resistance: 10MΩ or over with a DC500V Megger
- Maximum Airflow: 320 CFM
- Static Pressure: 0.90 in H2O
- Rated Voltage: 100V to 240V
- Frequency Range: 50Hz to 60Hz
- Max Speed: 3200 RPM
- Noise Level: Approximately 38-49 dB
- Expected Life: 80,000 hours at 26°C
- Rotation: Counterclockwise
- Inlet/Outlet: Air Out Over Struts, inlet side / outlet side
Buy the NMB 3115PS12WB10A00 – Reliable Axial Fan for Industrial Applications
Enhance your industrial cooling setup with the NMB 3115PS12WB10A00 axial fan, featuring durable aluminum casing and a robust polycarbonate impeller. It delivers up to 320 CFM airflow with a static pressure of 0.90 in H2O, suitable for reliable ventilation. Its energy-efficient design operates smoothly within a temperature range of -10°C to +70°C, ensuring long-lasting performance even in demanding environments. Compatible with standard lead wires or faston terminals, it offers easy installation and maintenance, making it an excellent choice for cooling and ventilation in manufacturing, electronics, and HVAC systems. Purchase online now for quick, secure delivery.
Order your NMB Series 3115PS12WB10A00 high-efficiency axial fan today and ensure optimal cooling performance for your industrial systems.
Frequently Asked Questions
Where can I buy NMB TECHNOLOGIES 3115PS12WB10A00?
You can click on the BUY or RFQ button to purchase 3115PS12WB10A00 from an authorized NMB TECHNOLOGIES distributor.
How do I troubleshoot issues or seek technical support for part 3115PS12WB10A00?
You can download the 3115PS12WB10A00 datasheet or visit the NMB TECHNOLOGIES website for support.
Who is the manufacturer of 3115PS12WB10A00?
NMB TECHNOLOGIES
