NVENT HOFFMAN APCDABS Pressure Compensation Device
The stainless steel pressure compensation device is made of Type 316L stainless steel with a semipermeable membrane inside the plug that filters moisture and dust. It features a mounting thread M40 with a union nut and a machined finish. Designed for use in challenging environments, this IP66-rated device offers slow pressure equalization to manage heat-generated pressure differentials in sealed electrical enclosures. Easy to install with a 41-mm diameter hole, it provides reliable corrosion resistance and optimal protection in corrosive applications, ensuring consistent performance.
NVENT HOFFMAN APCDABS Pressure Compensation Device Specifications:
- Material: Type 316L stainless steel
- Finish: Machined stainless steel
- Semipermeable membrane filters moisture and dust
- Mounting thread: M40 with union nut
- Sealing gasket: Nitrile Buna-N Rubber
- Air permeability: 42 cubic feet/hour (1,200 liters/hour) at 70 mbar pressure difference
- Installation hole diameter: 41 mm (1.60 in.)
- Unit dimensions: 726/580 x 1,227.81 mm
- Depth into enclosure: 38/9 mm
- Operating/Storage temperature: -45 to 158°F / -45 to 70°C
- Standards: UL Type 1, 4, 4X; IEC/EN 60529, IP66
- Application: Pressure equalization in sealed enclosures, corrosion-resistant for harsh environments
- Unit construction: Plastic pass, lightweight polymeric material
Buy the Buy Pentair Pressure Compensation Part Number APCDABS Online
Secure your electrical enclosures with the high-quality pressure compensation device. Made from durable Type 316L stainless steel with a semipermeable membrane, it filters moisture and dust efficiently. Easy to install with a 41-mm hole, it provides IP66 protection and corrosion resistance in harsh environments. Ideal for managing heat-induced pressure differentials, this device ensures your equipment operates safely and efficiently. Purchase online now for reliable, long-lasting pressure management in demanding industrial applications.
Order your Pentair Series APCDABS pressure compensation device today and ensure reliable pressure equalization and corrosion resistance in your sealed enclosures.
