NXP MRFX1K80NR5 Wideband RF Transistor
The MRFX1K80N is a high-power, broadband RF transistor designed for applications from 1.8 to 400 MHz, offering 1800 W CW output power at 65 V. Its rugged structure ensures high VSWR tolerance, making it ideal for broadcast, industrial, medical, and aerospace uses. This device features integrated ESD protection, high breakdown voltage, and can operate in single-ended or push-pull configurations. Suitable for linear amplification and RF power amplification, it is housed in a thermally efficient package with long-term supply assurance, making it perfect for demanding high-frequency applications.
NXP MRFX1K80NR5 Wideband RF Transistor Specifications:
- Frequency Range: 1.8 to 400 MHz
- Output Power: 1800 W CW at 65 V
- Peak Power Output: 24.4 dB (230 MHz pulse test)
- Voltage Rating: 179 VDS, 10 VGS
- Maximum Drain-Source Voltage: 179 V
- Gate-Source Voltage: ±10 V
- Storage Temperature Range: -65 to +150 °C
- Operating Temperature Range: -40 to +150 °C
- Thermal Resistance, Junction to Case: 0.06 °C/W
- Total Device Dissipation: 3333 W
- RF Frequency Support: 1.8 to 400 MHz
- Package Type: Non-JEDEC plastic package with exposed source tabs
- ESD Protection: Class 2 (Human Body Model 2500 V, Charged Device Model 1200 V)
Buy the NXP Semiconductors Series High Ruggedness RF Power Transistor: MRFX1K80NR5
Purchase the NXP MRFX1K80NR5 today and enhance your RF systems with a high-power, broadband transistor capable of handling from 1.8 to 400 MHz. This rugged device provides up to 1800 W CW output power at 65 V, ensuring reliable performance in broadcast, industrial, medical, and aerospace applications. With integrated ESD protection, high breakdown voltage, and a thermally efficient package, it guarantees long-lasting durability and exceptional linear amplification capabilities. Upgrade your RF design now with this industrial-grade power transistor capable of meeting demanding technical requirements.
Get NXP Semiconductors MRFX1K80NR5 today—built for high power, wide frequency range, and enduring reliability in demanding RF environments.
Frequently Asked Questions
Where can I buy NXP MRFX1K80NR5?
You can click on the BUY or RFQ button to purchase MRFX1K80NR5 from an authorized NXP distributor.
How do I troubleshoot issues or seek technical support for part MRFX1K80NR5?
You can download the MRFX1K80NR5 datasheet or visit the NXP website for support.
Who is the manufacturer of MRFX1K80NR5?
NXP
