OMEGA OS550WC Infrared Thermometer
The OS550 Series infrared thermometer/transmitter provides high-performance temperature measurement for industrial applications. It features a local backlit LCD display, laser sight option, and adjustable emissivity from 0.1 to 1.00 in 0.01 steps. With models measuring up to 1370°C (2500°F) and multiple outputs including mV/degree, 4-20 mA, and 0-5 Vdc, it offers fast 250 ms response time, robust NEMA 4 (IP66) enclosure, and optional accessories like mounting frames and air purge collars. Ideal for hostile environments, these sensors ensure accurate, reliable readings in temperature range from -18°C to 1370°C.
OMEGA OS550WC Infrared Thermometer Specifications:
- Accuracy: +1% of reading @ 25°C or 1.7°C (3°F), whichever is greater
- Repeatability: +1% of reading +1 digit
- Spectral Response: 8 to 14 microns
- Emissivity Range: 0.10 to 1.00
- Field of View: See diagram
- Display: Backlit LCD
- Outputs: 1 mV/degree, 0 to 5 Vdc, 4 to 20 mA
- Power Supply: 7 to 24 Vdc @ 80 mA
- Environmental Rating: NEMA 4 (IP66)
- Ambient Operating Range: Sensing head 0 to 50°C (with OS550-WC), 0 to 85°C
- Response Time: 250 ms
- Alarm Indicators: Visual and audible
- Communication: RS232 (standard on models OS552, OS553, OS554)
- Dimensions: Sensing Head 10.9 x 4.1 cm (4.30 x 1.63 inches), Electronics 13.3 x 9.1 cm (5.25 x 3.62 inches)
- Weight: Sensing Head 0.45 kg (12 oz), Enclosure 1.2 kg (43.2 oz)
Buy the Buy Omega Infrared Thermometer Part Number OS550WC Online
Experience the reliability and precision of the Omega OS550WC infrared thermometer, designed for demanding industrial applications. It features a backlit LCD display, adjustable emissivity from 0.1 to 1.00, three output options including mV/degree, 4-20 mA, and 0-5 Vdc, and an IP66 rated enclosure. With a rapid 250 ms response time and a temperature range up to 1370°C, this sensor ensures durable, accurate measurements in hostile environments. Ideal for maintenance, manufacturing, and process control, it is available for quick online purchase.
Buy Omega OS550WC infrared thermometer now and ensure accurate, fast temperature measurement in harsh industrial environments.
Frequently Asked Questions
Where can I buy OMEGA OS550WC?
You can click on the BUY or RFQ button to purchase OS550WC from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part OS550WC?
You can download the OS550WC datasheet or visit the OMEGA website for support.
Who is the manufacturer of OS550WC?
OMEGA
