OMEGA PSW1110150GP5V digital pressure switch
The PSW-1110 is a compact digital pressure switch featuring a bright 4-digit programmable display for real-time pressure monitoring. Designed for non-corrosive gases, it provides accurate +1% FS measurement, with flexible mounting options including vertical and horizontal ports. The device offers two main output modes, hysteresis and window modes, with programmable high and low setpoints, and eight pressure units including psi, bar, and KPa. Its versatile, mini size makes it ideal for industrial automation, process control, and system monitoring applications, ensuring reliable, precise pressure detection.
OMEGA PSW1110150GP5V digital pressure switch Specifications:
- Accuracy +1% FS
- Repeatability +1% FS
- Response Time 135 ms
- Burst Pressure 300 psi
- Compatible Media Non-Corrosive Gasses
- Supply Voltage 10-30 Vdc
- Current Consumption <80 mA
- Output PNP
- Media Temperature Range 0 to 100°C
- Temperature Accuracy +2°C
- Operating Temperature -10 to 60°C
- Storage Temperature -20 to 70°C
- Operating & Storage Humidity 35 to 85% RH
- Process Connection Material Zinc Alloy
- Enclosure Materials ABS
- Weight 80g
- Shock 100g
- Vibration 10 to 500 Hz, 0.06” amplitude
Buy the Oz OMEGA PSW-1110 – Reliable Digital Pressure Switch for Industrial Applications
Purchase the Oz OMEGA PSW-1110 digital pressure switch online today for precise non-corrosive gas pressure monitoring. Its compact 1-inch cube design allows versatile mounting options including vertical and horizontal ports, making installation simple and flexible in any industrial setting. Equipped with a programmable 4-digit display, eight pressure units, and fully configurable output modes like hysteresis and window mode, this device offers high accuracy (+1% FS), fast response time (135 ms), and reliable operation across a wide temperature range. Perfect for automation, system control, and process management, ensuring durability and ease of use.
Get Oz OMEGA PSW-1110 today—built for precision and long-lasting durability with programmable outputs and multi-unit pressure display.
Frequently Asked Questions
Where can I buy OMEGA PSW1110150GP5V?
You can click on the BUY or RFQ button to purchase PSW1110150GP5V from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PSW1110150GP5V?
You can download the PSW1110150GP5V datasheet or visit the OMEGA website for support.
Who is the manufacturer of PSW1110150GP5V?
OMEGA
