ONSEMI FDB3682 Power MOSFET
The FDB3682 and FDP3682 are N-Channel PowerTrench MOSFETs designed for high-efficiency power switching applications. Featuring a maximum drain-source voltage of 100 V and a continuous drain current of 32 A at 25°C, these devices offer low on-resistance (RDS(on)) of 0.040–0.060 Ω at 16–32 A, ensuring minimal power loss. They also have low gate charge, body diode with low reverse recovery charge, and UIS capability for single and repetitive pulses. Suitable for motor drives, battery protection circuits, and uninterruptible power supplies, these MOSFETs provide reliable performance in demanding environments.
ONSEMI FDB3682 Power MOSFET Specifications:
- Drain to Source Voltage: 100 V
- Gate to Source Voltage: ±420 V
- Continuous Drain Current: 32 A at 25°C
- Maximum Power Dissipation: 95 W
- Power Derating above 25°C: 0.63 W/°C
- Operating and Storage Temperature: -55 to 175 °C
- Thermal Resistance Junction to Case: Max. 1.58 °C/W (TO-220, TO-263)
- Thermal Resistance Junction to Ambient: Max. 62 °C/W (TO-220, TO-263)
Buy the Fairchild FDB3682 U-2013 Reliable Power MOSFET for Industrial Applications
Discover the reliable and efficient FDB3682 power MOSFET available now online. With a maximum drain-source voltage of 100 V and a continuous drain current of 32 A, this device provides low on-resistance and excellent efficiency for industrial power switching, motor drives, and battery protection circuits. Its low gate charge and superior thermal performance ensure optimal operation in demanding environments, making it the ideal choice for engineers seeking high-quality, dependable switching components for their designs.
Order your Fairchild SeriesFDP3682 high-efficiency power MOSFET today and enhance your power switching and motor control projects with dependable performance.
Frequently Asked Questions
Where can I buy ONSEMI FDB3682?
You can click on the BUY or RFQ button to purchase FDB3682 from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part FDB3682?
You can download the FDB3682 datasheet or visit the ONSEMI website for support.
Who is the manufacturer of FDB3682?
ONSEMI
