ONSEMI FOD8482 Optocoupler Module
The FOD8482 is a low power optocoupler designed for isolated digital control signals in industrial and automation applications. Packaged in a compact stitched body SOP 6-pin, it features aluminum gallium arsenide (AlGaAs) LED and a high gain detector with hysteresis for noise immunity. Suitable for isolating intelligent power modules and communication interfaces, the device offers high insulation voltage, wide operating voltage range, and guaranteed performance from -40°C to 100°C, ensuring reliable and safe electrical isolation with low input current requirements.
ONSEMI FOD8482 Optocoupler Module Specifications:
- Input Current (Ip): 5.5 mA (FOD8480), 3.0 mA (FOD8482)
- Isolation Voltage: 5,000 VACrms
- Peak Working Insulation Voltage: 1,140 V peak
- Creepage/clearance: 8 mm / 8 mm
- Maximum Input Power Dissipation: 35 mW
- Maximum Output Power Dissipation: 300 mW
- Operating Temperature Range: -40°C to 100°C
- Supply Voltage Range: 4.5 V to 30 V
- Input Reverse Voltage: 5.0 V
- Output Voltage: 0 to 35 V
- Response Time: Propagation delay 130–300 ns, Rise time 15 ns, Fall time 10 ns
- High Noise Immunity: 20 kV/μs CMTI
- Safety Approvals: UL1577, IEC 60747-5-5
- Insulation Resistance: 10^9Ω at 500 V
Buy the ON Semiconductor FOD8482 – Reliable Isolated Power Control Module for Industrial Applications
Purchase the ON Semiconductor FOD8482 optocoupler online to ensure safe electrical isolation in industrial systems. With a compact SOP 6-pin package, it provides high insulation voltage, noise immunity, and wide operating voltage across a temperature range of -40°C to 100°C. Designed for isolating intelligent power modules and industrial communication interfaces, it guarantees performance, safety, and reliability in your automation and control applications. Shop now to benefit from fast delivery and expert support for your high-performance system needs.
Get ON Semiconductor FOD8482 today—built for precision and long-lasting durability in industrial control and communication systems.
Frequently Asked Questions
Where can I buy ONSEMI FOD8482?
You can click on the BUY or RFQ button to purchase FOD8482 from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part FOD8482?
You can download the FOD8482 datasheet or visit the ONSEMI website for support.
Who is the manufacturer of FOD8482?
ONSEMI
