ONSEMI GBPC1204W Bridge Rectifier
The GBPC1204W is a glass passivated bridge rectifier designed for high-current applications in power conversion systems. It features an integrally molded heat sink for efficient heat dissipation, surge overload ratings up to 400 A, and an isolated voltage from case to lead exceeding 2500 V. This model includes silver-plated terminals with optional face-to-face terminal configuration (suffix M) or wire lead structure (suffix W). UL certified, it offers reliable performance for industrial power supply, motor drives, and high-voltage rectification circuits, ensuring durability and safety in demanding environments.
ONSEMI GBPC1204W Bridge Rectifier Specifications:
- Maximum Repetitive Reverse Voltage: 50 V
- Maximum RMS Bridge Input Voltage: 35 V
- DC Reverse Voltage: 50 V
- Surge Overload Rating: 300 A (GBPC12), 400 A (GBPC35)
- Operating Temperature Range: -55°C to +150°C
- Power Dissipation: 83.3 W
- Thermal Resistance, Junction to Case: 15 °C/W
- Forward Voltage Drop: Max 1.1 V at 6.0 A (GBPC12), Max 1.1 V at 7.5 A (GBPC15), Max 5.0 V at 125 A (GBPC25), Max 17.5 V at 35 A (GBPC35)
- Reverse Current at Rated Voltage: Max 500 μA at 125°C
- Isolation Voltage from case to lead: >2500 V
- Terminal Finish Material: Silver (solderable), Nickel for package
- Dimensions: 17.6 mm x 15.5 mm x (varies per model), with specific sizes detailed in datasheet
- Manufactured with glass passivation for long-term reliability
Buy the ON Semiconductor GBPC1204W – Reliable Bridge Rectifier for Industrial Applications
Order the ON Semiconductor GBPC1204W online today for high-current rectification needs. Featuring excellent thermal management, surge overload ratings up to 400 A, and UL certification, this glass passivated bridge rectifier is ideal for industrial power supplies, motor drives, and high-voltage applications. Its compact design, glass passivation, and high isolation voltage ensure reliable, long-lasting performance in demanding environments. Buy now and enhance your power conversion systems with proven durability and safety.
Get ON Semiconductor GBPC1204W today—built for high-current power rectification and robust industrial performance.
Frequently Asked Questions
Where can I buy ONSEMI GBPC1204W?
You can click on the BUY or RFQ button to purchase GBPC1204W from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part GBPC1204W?
You can download the GBPC1204W datasheet or visit the ONSEMI website for support.
Who is the manufacturer of GBPC1204W?
ONSEMI
